一、环境准备
system：CentOS_6.6
IP：192.168.30.129
安装yum：
rpm -Uhv http://dl.fedoraproject.org/pub/epel/6/x86_64/epel-release-6-8.noarch.rpm 二、安装SVN
root@pts/0 # yum -y install subversion
Loaded plugins: fastestmirror, security
Setting up Install Process
Determining fastest mirrors
epel/metalink | 5.0 kB 00:00
* base: mirrors.btte.net
* epel: mirrors.opencas.cn
* extras: mirrors.btte.net
* updates: mirrors.btte.net
base | 3.7 kB 00:00
base/primary_db | 4.6 MB 00:06
epel | 4.3 kB 00:00
epel/primary_db | 5.7 MB 00:44
extras | 2.9 kB 00:00
extras/primary_db | 33 kB 00:00
updates | 3.4 kB 00:00
updates/primary_db | 3.3 MB 00:04
Resolving Dependencies
--> Running transaction check
---> Package subversion.x86_64 0:1.6.11-15.el6_7 will be installed
--> Finished Dependency Resolution
Dependencies Resolved
=========================================================================================================================================
Package Arch Version Repository > 输入rpm -ql subversion查看安装位置
root@pts/0 # rpm -ql subversion
/etc/bash_completion.d
/etc/bash_completion.d/subversion
/etc/rc.d/init.d/svnserve
/etc/subversion
/usr/bin/svn
/usr/bin/svnadmin
/usr/bin/svndumpfilter
/usr/bin/svnlook
/usr/bin/svnserve
/usr/bin/svnsync
/usr/bin/svnversion
.... 查看svn 帮助
root@pts/0 # svn --help
usage: svn <subcommand> [options] [args]
Subversion command-line client, version 1.6.11.
Type 'svn help <subcommand>' for help on a specific subcommand.
Type 'svn --version' to see the program version and RA modules
or 'svn --version --quiet' to see just the version number.
Most subcommands take file and/or directory arguments, recursing
on the directories. If no arguments are supplied to such a
command, it recurses on the current directory (inclusive) by default.
Available subcommands:
add
blame (praise, annotate, ann)
cat
changelist (cl)
checkout (co)
cleanup
commit (ci)
copy (cp)
delete (del, remove, rm)
diff (di)
export
help (?, h)
import
info
list (ls)
lock
log
merge
mergeinfo
mkdir
move (mv, rename, ren)
propdel (pdel, pd)
propedit (pedit, pe)
propget (pget, pg)
proplist (plist, pl)
propset (pset, ps)
resolve
resolved
revert
status (stat, st)
switch (sw)
unlock
update (up)
Subversion is a tool for version control.
For additional information, see http://subversion.tigris.org/
root@pts/0 # svnadmin --help
general usage: svnadmin SUBCOMMAND REPOS_PATH [ARGS & OPTIONS ...]
Type 'svnadmin help <subcommand>' for help on a specific subcommand.
Type 'svnadmin --version' to see the program version and FS modules.
Available subcommands:
crashtest
create
deltify
dump
help (?, h)
hotcopy
list-dblogs
list-unused-dblogs
load
lslocks
lstxns
pack
recover
rmlocks
rmtxns
setlog
setrevprop
setuuid
upgrade
verify 三、创建svn版本库目录
root@pts/0 # mkdir -p /usr/local/svn/test 四、创建版本库
root@pts/0 # svnadmin create /usr/local/svn/test
Test_1 [~] 2016-01-10 15:03:28
root@pts/0 # ll /usr/local/svn/test
total 24
drwxr-xr-x. 2 root root 4096 Jan 10 15:03 conf
drwxr-sr-x. 6 root root 4096 Jan 10 15:03 db
-r--r--r--. 1 root root 2 Jan 10 15:03 format
drwxr-xr-x. 2 root root 4096 Jan 10 15:03 hooks
drwxr-xr-x. 2 root root 4096 Jan 10 15:03 locks
-rw-r--r--. 1 root root 229 Jan 10 15:03 README.txt 五、进入conf目录（该svn版本库配置文件）
root@pts/0 # cd conf/
Test_1 [/usr/local/svn/test/conf] 2016-01-10 15:12:38
root@pts/0 # ll
total 12
-rw-r--r--. 1 root root 1080 Jan 10 15:03 authz
-rw-r--r--. 1 root root 309 Jan 10 15:03 passwd
-rw-r--r--. 1 root root 2279 Jan 10 15:03 svnserve.conf authz文件是权限控制文件
passwd是帐号密码文件
svnserve.conf SVN服务配置文件
六、设置帐号密码
root@pts/0 # vim passwd
### This file is an example password file for svnserve.
### Its format is similar to that of svnserve.conf. As shown in the
### example below it contains one section labelled [users].
### The name and password for each user follow, one account per line.
[users]
# harry = harryssecret
# sally = sallyssecret
test = test123
other = test123 在[users]块中添加用户和密码，格式：帐号=密码，如test = test123
七、设置权限
root@pts/0 # vim authz
....
[/]
test = rw
other = r 意思是版本库的根目录test对其有读写权限，other只有读权限。
九、启动svn版本库
root@pts/0 # svnserve -d -r /usr/local/svn
root@pts/0 # ps -ef |grep svn
root 3082 1 0 15:31 ? 00:00:00 svnserve -d -r /usr/local/svn 十、测试连接
root@pts/0 # mkdir -p /opt/test
Test_1 [/opt] 2016-01-10 15:37:01
root@pts/0 # cd /opt/test/
Test_1 [/opt/test] 2016-01-10 15:37:08
root@pts/0 # svn co svn://127.0.0.1/test /opt/test/
Authentication realm: <svn://127.0.0.1:3690> /usr/local/svn/test
Password for 'root':
Authentication realm: <svn://127.0.0.1:3690> /usr/local/svn/test
Username: test
Password for 'test':
-----------------------------------------------------------------------
ATTENTION! Your password for authentication realm:
<svn://127.0.0.1:3690> /usr/local/svn/test
can only be stored to disk unencrypted! You are advised to configure
your system so that Subversion can store passwords encrypted, if
possible. See the documentation for details.
You can avoid future appearances of this warning by setting the value
of the 'store-plaintext-passwords' option to either 'yes' or 'no' in
'/root/.subversion/servers'.
-----------------------------------------------------------------------
Store password unencrypted (yes/no)? yes
Checked out revision 0.
root@pts/0 # svn info
Path: .
URL: svn://127.0.0.1/test
Repository Root: svn://127.0.0.1/test
Repository UUID: ec5619f6-c7b2-4018-a560-616f7d6462cc
Revision: 0
Node Kind: directory
Schedule: normal
Last Changed Rev: 0
Last Changed Date: 2016-01-10 15:45:56 +0000 (Sun, 10 Jan 2016) linux svn 更多命令可以查询帮助信息！
十一、测试上传文件，查看版本
root@pts/0 # touch file
Test_1 [/opt/test] 2016-01-10 16:15:57
root@pts/0 # echo "svn is test" > file
Test_1 [/opt/test] 2016-01-10 16:16:14
root@pts/0 # svn add file
A file
Test_1 [/opt/test] 2016-01-10 16:16:21
root@pts/0 # svn commit file -m 'test'
Adding file
Transmitting file data .
Committed revision 1.
Test_1 [/opt/test] 2016-01-10 16:16:56
root@pts/0 # ll
total 4
-rw-r--r--. 1 root root 12 Jan 10 16:16 file
Test_1 [/opt/test] 2016-01-10 16:17:08
root@pts/0 # svn info file
Path: file
Name: file
URL: svn://127.0.0.1/test/file
Repository Root: svn://127.0.0.1/test
Repository UUID: ec5619f6-c7b2-4018-a560-616f7d6462cc
Revision: 1
Node Kind: file
Schedule: normal
Last Changed Author: test
Last Changed Rev: 1
Last Changed Date: 2016-01-10 16:16:42 +0000 (Sun, 10 Jan 2016)
Text Last Updated: 2016-01-10 16:16:14 +0000 (Sun, 10 Jan 2016)
Checksum: 304b5e95556c9066f5aa1268ede6df6a 显示版本已更新为 1
