Nagios 3.0 Jumpstart Guide For Linux – Overview, Installation and Configuration

61581229

　　Let us discuss the overview, installation and configuration of Nagios, a powerful open source monitoring solution for host and services.

I. Overview of nagios
　　II. 8 steps for installing nagios on Linux:

• Download the nagios and plugins

• Take care of the prerequisites

• Create user and group for nagios

• Install nagios

• Configure the web interface

• Compile and install nagios plugins

• Start Nagios

• Login to web interface


　　III. Configuration files overview
　　


I. Overview of Nagios
　　.
Nagios is a host and service monitor tool. Following are some of the features of nagios.

• Monitor equipments such as servers, switches, routers, firewalls, power supply etc.

• Monitor services such as disk space, cpu usage, memory usage, temperature of the equipment, HTTP, Mail, SSH etc.

• Nagios can monitor pretty much anything. for e.g. host, services, databases, applications etc.

• Nagios has an extensible plugin interface for monitoring user defined services. There are lot of plugins available for Nagios. Visit NagiosPlugins and NagiosExchange for review the available user developed plugins.

• It can send out various notifications ( email, pager etc.) when the problem occurs and get resolved.

• Web interface to view current status, notifications, problem history, log files etc.


　　Following is a partial screenshot of the nagios web dashboard:






Fig: Nagios Web UI (click on the image to enlarge)

II. 8 steps for installing nagios on Linux:

1. Download the nagios and plugins
　　Download following files from Nagios.org and move to /home/downloads

• nagios-3.0.1.tar.gz

• nagios-plugins-1.4.11.tar.gz


2. Take care of the prerequisites

• Make sure apache is working on the server by verifying from browser: http://localhost

• Verify whether gcc is installed


      [iyunv@localhost]#rpm -qa | grep gcc
      gcc-3.4.6-8
      compat-gcc-32-3.2.3-47.3
      libgcc-3.4.6-8
      compat-libgcc-296-2.96-132.7.2
      compat-gcc-32-c++-3.2.3-47.3
      gcc-c++-3.4.6-8

• Verify whether GD is installed


    [iyunv@localhost]# rpm -qa gd
      gd-2.0.28-5.4E

3. Create user and group for nagios



[iyunv@localhost]# useradd nagios
[iyunv@localhost]# passwd nagios
[iyunv@localhost]# groupadd nagcmd
[iyunv@localhost]# usermod -G nagcmd nagios
[iyunv@localhost]# usermod -G nagcmd apache


4. Install nagios



[iyunv@localhost]# tar xvf nagios-3.0.1.tar.gz
[iyunv@localhost]# cd nagios-3.0.1
[iyunv@localhost]# ./configure --with-command-group=nagcmd
[iyunv@localhost]# make all
[iyunv@localhost]# make install
[iyunv@localhost]# make install-config
[iyunv@localhost]# make install-commandmode


　　Following are some additional parameters that you can pass to ./configure to customize your installation. I used only --with-command-group as shown above.



    --prefix              /opt/nagios    Where to put the Nagios files
    --with-cgiurl         /nagios/cgi-bin    Web server url where the cgi's will be available
    --with-htmurl         /nagios        Web server url where nagios will be available
    --with-nagios-user    nagios        user account under which Nagios will run
    --with-nagios-group    nagios        group account under which Nagios will run
    --with-command-group    nagcmd        group account which will allow the apache user to submit
                        commands to Nagios


　　At the end of the configure output, it will display a summary as shown below:



*** Configuration summary for nagios 3.0.1 05-28-2008 ***:
General Options:
-------------------------
Nagios executable:  nagios
Nagios user/group:  nagios,nagios
Command user/group:  nagios,nagcmd
Embedded Perl:  no
Event Broker:  yes
Install ${prefix}:  /usr/local/nagios
Lock file:  ${prefix}/var/nagios.lock
Check result directory:  ${prefix}/var/spool/checkresults
Init directory:  /etc/rc.d/init.d
Apache conf.d directory:  /etc/httpd/conf.d
Mail program:  /bin/mail
Host OS:  linux-gnu
Web Interface Options:
------------------------
HTML URL:  http://localhost/nagios/
CGI URL:  http://localhost/nagios/cgi-bin/
Traceroute (used by WAP):  /bin/traceroute


5. Configure the web interface.



[iyunv@localhost]# make install-webconf
[iyunv@localhost# htpasswd -c /usr/local/nagios/etc/htpasswd.users nagiosadmin
New password:
Re-type new password:
Adding password for user nagiosadmin


6. Compile and install nagios plugins



[iyunv@localhost]# tar xvf nagios-plugins-1.4.11.tar.gz
[iyunv@localhost]# cd nagios-plugins-1.4.11
[iyunv@localhost]# ./configure --with-nagios-user=nagios --with-nagios-group=nagios
[iyunv@localhost]# make
[iyunv@localhost]# make install


　　Note: On Red Hat, the ./configure command mentioned above did not work and was hanging at the when it was displaying the message: checking for redhat spopen problem… Add –enable-redhat-pthread-workaround to the ./configure command as a work-around for the above problem as shown below.



[iyunv@localhost]# ./configure --with-nagios-user=nagios --with-nagios-group=nagios --enable-redhat-pthread-workaround


7. Start Nagios

• Add the nagios to the startup routine:


      [iyunv@localhost]# chkconfig --add nagios
      [iyunv@localhost]# chkconfig nagios on

• Verify to make sure there are no errors in the nagios configuration file:


      [iyunv@localhost]# /usr/local/nagios/bin/nagios -v /usr/local/nagios/etc/nagios.cfg
      Total Warnings: 0
      Total Errors:   0
      Things look okay - No serious problems were detected during the pre-flight check

• Start the nagios


      [iyunv@localhost]# service nagios start
      Starting nagios: done.


8. Login to web interface
　　Nagios Web URL: http://localhost/nagios/
Use the userid, password that was created from step#5 above.
　　


III. Configuration files overview
　　.
The first configuration to modify is to change the default value of email address in /usr/local/nagios/etc/objects/contacts.cfg file to your email address.
　　Following are the three major configuration files located under /usr/local/nagios/etc

• nagios.cfg – This is the primary Nagios configuration file where lot of global parameters that controls the nagios can be defined.

• cgi.cfg - This files has configuration information for nagios web interface.

• resource.cfg – If you have to pass some sensitive information (username, password etc.) to a plugin to monitor a specific service, you can define them here. This file is readable only by nagios user and group.


　　Following are the other configuration files under /usr/local/nagios/etc/objects directory:

• contacts.cfg: All the contacts who needs to be notified should be defined here. You can specify name, email address, what type of notifications they need to receive and what is the time period this particular contact should be receiving notifications etc.

• commands.cfg – All the commands to check services are defined here. You can use $HOSTNAME$ and $HOSTADDRESS$ macro on the command execution that will substitute the corresponding hostname or host ip-address automatically.

• timeperiods.cfg – Define the timeperiods. for e.g. if you want a service to be monitored only during the business hours, define a time period called businesshours and specify the hours that you would like to monitor.

• templates.cfg – Multiple host or service definition that has similar characteristics can use a template, where all the common characteristics can be defined. Use template is a time saver.

• localhost.cfg – Defines the monitoring for the local host. This is a sample configuration file that comes with nagios installation that you can use as a baseline to define other hosts that you would like to monitor.

• printer.cfg – Sample config file for printer

• switch.cfg – Sample config file for switch

• windows.cfg – Sample config file for a windows machine


　　I will discuss about the steps to configure a remote Linux Host and Windows Host for monitoring through nagios inupcoming posts.
