perl-opengl几何变换函数

zhouu

• #!/usr/bin/perl -w

• use strict;

• use warnings;

• use OpenGL qw/ :all /;

• use OpenGL::Config;

•

• glutInit();

• glutInitDisplayMode(GLUT_RGB|GLUT_SINGLE);

• glutInitWindowPosition(100,100);

• glutInitWindowSize(400,400);

• glutCreateWindow("opengl");

• glClearColor(0,0,0,255);


• glClear(GL_COLOR_BUFFER_BIT);

• glMatrixMode(GL_PROJECTION);

• gluOrtho2D(-100,100,-100,100);


• glMatrixMode(GL_MODELVIEW);

• glutDisplayFunc(\&mydis);

• glutMainLoop();

• return 0;

•

• sub mydis()

• {

•   glClearColor(0,0,0,255);


•   glClear(GL_COLOR_BUFFER_BIT);

•   glLoadIdentity();

•   glPolygonMode(GL_FRONT_AND_BACK, GL_LINE);

•   glColor3f(1,1,1);


•   glBegin(GL_LINES);

•   glVertex2f(-100,0);

•   glVertex2f(100,0);

•   glEnd();

•   glBegin(GL_LINES);

•   glVertex2f(0,-100);

•   glVertex2f(0,100);

•   glEnd();

•   # 画矩形

•   glColor3f(0.5,0.1,0);


•   glRecti(-50,-50,50,50);


•   glFlush();

•   glPushMatrix();

•   #向x方向移动3.5个单位,y方向移动8.5个单位

•   glColor3f(0.1,0.1,0.9);


•   glTranslatef(3.5,8.5,0);


•   glRecti(-50,-50,50,50);


•   glFlush();

•   glPopMatrix();

•   glPushMatrix();

•   #x方向放大到1.2倍，y方向放大到1.8倍

•   glColor3f(0.1,0.9,0.1);


•   glScalef(1.2,1.8,1);


•   glRecti(-50,-50,50,50);


•   glFlush();

•   glPopMatrix();

•   glPushMatrix();

•   #x方向缩小至0.5倍，y方向缩小至0.8倍

•   glColor3f(0.9,0.9,0.9);


•   glScalef(0.5,0.8,1);


•   glRecti(-50,-50,50,50);


•   glFlush();

•   glPopMatrix();

•   glPushMatrix();

•   #二维旋转，相对于坐标原点的

•   glColor3f(0.7,0.8,0.7);


•   my ($x1,$y1,$x2,$y2)=(15,15,15,50);


•   for (my $theta=5;$theta<360;$theta&#43;=5)


•   {

•     glRotatef($theta,0,0,1);#相对于z轴


•     glRecti(-50,-50,50,50);


•   }

•   glFlush();

• }


#!/usr/bin/perl -w
use strict;
use warnings;
use OpenGL qw/ :all /;
use OpenGL::Config;
glutInit();
glutInitDisplayMode(GLUT_RGB|GLUT_SINGLE);
glutInitWindowPosition(100,100);
glutInitWindowSize(400,400);
glutCreateWindow(&quot;opengl&quot;);
glClearColor(0,0,0,255);
glClear(GL_COLOR_BUFFER_BIT);
glMatrixMode(GL_PROJECTION);
gluOrtho2D(-100,100,-100,100);
glMatrixMode(GL_MODELVIEW);
glutDisplayFunc(\&mydis);
glutMainLoop();
return 0;
sub mydis()
{
glClearColor(0,0,0,255);
glClear(GL_COLOR_BUFFER_BIT);
glLoadIdentity();
glPolygonMode(GL_FRONT_AND_BACK, GL_LINE);
glColor3f(1,1,1);
glBegin(GL_LINES);
glVertex2f(-100,0);
glVertex2f(100,0);
glEnd();
glBegin(GL_LINES);
glVertex2f(0,-100);
glVertex2f(0,100);
glEnd();
# 画矩形
glColor3f(0.5,0.1,0);
glRecti(-50,-50,50,50);
glFlush();
glPushMatrix();
#向x方向移动3.5个单位,y方向移动8.5个单位
glColor3f(0.1,0.1,0.9);
glTranslatef(3.5,8.5,0);
glRecti(-50,-50,50,50);
glFlush();
glPopMatrix();
glPushMatrix();
#x方向放大到1.2倍，y方向放大到1.8倍
glColor3f(0.1,0.9,0.1);
glScalef(1.2,1.8,1);
glRecti(-50,-50,50,50);
glFlush();
glPopMatrix();
glPushMatrix();
#x方向缩小至0.5倍，y方向缩小至0.8倍
glColor3f(0.9,0.9,0.9);
glScalef(0.5,0.8,1);
glRecti(-50,-50,50,50);
glFlush();
glPopMatrix();
glPushMatrix();
#二维旋转，相对于坐标原点的
glColor3f(0.7,0.8,0.7);
my ($x1,$y1,$x2,$y2)=(15,15,15,50);
for (my $theta=5;$theta<360;$theta+=5)
{
glRotatef($theta,0,0,1);#相对于z轴
glRecti(-50,-50,50,50);
}
glFlush();
}
