Oracle 12c RAC Flex Cluster & Flex ASM安装配置截图

6544t

配置dhcp和dns服务器过程省略

--root.sh

[iyunv@vzwc1 ~]# /u01/app/12.1.0/grid/root.sh
Performing root user operation for Oracle 12c


The following environment variables are set as:
    ORACLE_OWNER= grid
    ORACLE_HOME=  /u01/app/12.1.0/grid


Enter the full pathname of the local bin directory: [/usr/local/bin]:
   Copying dbhome to /usr/local/bin ...
   Copying oraenv to /usr/local/bin ...
   Copying coraenv to /usr/local/bin ...




Creating /etc/oratab file...
Entries will be added to the /etc/oratab file as needed by
Database Configuration Assistant when a database is created
Finished running generic part of root script.
Now product-specific root actions will be performed.
Using configuration parameter file: /u01/app/12.1.0/grid/crs/install/crsconfig_params
2014/03/31 22:27:28 CLSRSC-363: User ignored prerequisites during installation


OLR initialization - successful
  root wallet
  root wallet cert
  root cert export
  peer wallet
  profile reader wallet
  pa wallet
  peer wallet keys
  pa wallet keys
  peer cert request
  pa cert request
  peer cert
  pa cert
  peer root cert TP
  profile reader root cert TP
  pa root cert TP
  peer pa cert TP
  pa peer cert TP
  profile reader pa cert TP
  profile reader peer cert TP
  peer user cert
  pa user cert
2014/03/31 22:28:16 CLSRSC-330: Adding Clusterware entries to file 'oracle-ohasd.conf'


CRS-4133: Oracle High Availability Services has been stopped.
CRS-4123: Oracle High Availability Services has been started.
CRS-4133: Oracle High Availability Services has been stopped.
CRS-4123: Oracle High Availability Services has been started.
CRS-2673: Attempting to stop 'ora.drivers.acfs' on 'vzwc1'
CRS-2677: Stop of 'ora.drivers.acfs' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.evmd' on 'vzwc1'
CRS-2672: Attempting to start 'ora.mdnsd' on 'vzwc1'
CRS-2676: Start of 'ora.evmd' on 'vzwc1' succeeded
CRS-2676: Start of 'ora.mdnsd' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.gpnpd' on 'vzwc1'
CRS-2676: Start of 'ora.gpnpd' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.cssdmonitor' on 'vzwc1'
CRS-2672: Attempting to start 'ora.gipcd' on 'vzwc1'
CRS-2676: Start of 'ora.cssdmonitor' on 'vzwc1' succeeded
CRS-2676: Start of 'ora.gipcd' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.cssd' on 'vzwc1'
CRS-2672: Attempting to start 'ora.diskmon' on 'vzwc1'
CRS-2676: Start of 'ora.diskmon' on 'vzwc1' succeeded
CRS-2676: Start of 'ora.cssd' on 'vzwc1' succeeded


ASM created and started successfully.


Disk Group CRSDG created successfully.


CRS-2672: Attempting to start 'ora.crf' on 'vzwc1'
CRS-2672: Attempting to start 'ora.storage' on 'vzwc1'
CRS-2676: Start of 'ora.storage' on 'vzwc1' succeeded
CRS-2676: Start of 'ora.crf' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.crsd' on 'vzwc1'
CRS-2676: Start of 'ora.crsd' on 'vzwc1' succeeded
CRS-4256: Updating the profile
Successful addition of voting disk 51332438a70f4f9bbfa2929f3d26d842.
Successfully replaced voting disk group with +CRSDG.
CRS-4256: Updating the profile
CRS-4266: Voting file(s) successfully replaced
##  STATE    File Universal Id                File Name Disk group
--  -----    -----------------                --------- ---------
1. ONLINE   51332438a70f4f9bbfa2929f3d26d842 (/dev/asm-diskd) [CRSDG]
Located 1 voting disk(s).
CRS-2791: Starting shutdown of Oracle High Availability Services-managed resources on 'vzwc1'
CRS-2673: Attempting to stop 'ora.crsd' on 'vzwc1'
CRS-2677: Stop of 'ora.crsd' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.gpnpd' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.evmd' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.storage' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.mdnsd' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.drivers.acfs' on 'vzwc1'
CRS-2677: Stop of 'ora.storage' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.drivers.acfs' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.gpnpd' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.mdnsd' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.evmd' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.crf' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.ctssd' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.asm' on 'vzwc1'
CRS-2677: Stop of 'ora.crf' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.ctssd' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.asm' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.cluster_interconnect.haip' on 'vzwc1'
CRS-2677: Stop of 'ora.cluster_interconnect.haip' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.cssd' on 'vzwc1'
CRS-2677: Stop of 'ora.cssd' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.gipcd' on 'vzwc1'
CRS-2677: Stop of 'ora.gipcd' on 'vzwc1' succeeded
CRS-2793: Shutdown of Oracle High Availability Services-managed resources on 'vzwc1' has completed
CRS-4133: Oracle High Availability Services has been stopped.
CRS-4123: Starting Oracle High Availability Services-managed resources
CRS-2672: Attempting to start 'ora.mdnsd' on 'vzwc1'
CRS-2672: Attempting to start 'ora.evmd' on 'vzwc1'
CRS-2676: Start of 'ora.evmd' on 'vzwc1' succeeded
CRS-2676: Start of 'ora.mdnsd' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.gpnpd' on 'vzwc1'
CRS-2676: Start of 'ora.gpnpd' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.gipcd' on 'vzwc1'
CRS-2676: Start of 'ora.gipcd' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.cssdmonitor' on 'vzwc1'
CRS-2676: Start of 'ora.cssdmonitor' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.cssd' on 'vzwc1'
CRS-2672: Attempting to start 'ora.diskmon' on 'vzwc1'
CRS-2676: Start of 'ora.diskmon' on 'vzwc1' succeeded
CRS-2789: Cannot stop resource 'ora.diskmon' as it is not running on server 'vzwc1'
CRS-2676: Start of 'ora.cssd' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.cluster_interconnect.haip' on 'vzwc1'
CRS-2672: Attempting to start 'ora.ctssd' on 'vzwc1'
CRS-2676: Start of 'ora.ctssd' on 'vzwc1' succeeded
CRS-2676: Start of 'ora.cluster_interconnect.haip' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.asm' on 'vzwc1'
CRS-2676: Start of 'ora.asm' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.storage' on 'vzwc1'
CRS-2676: Start of 'ora.storage' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.crf' on 'vzwc1'
CRS-2676: Start of 'ora.crf' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.crsd' on 'vzwc1'
CRS-2676: Start of 'ora.crsd' on 'vzwc1' succeeded
CRS-6023: Starting Oracle Cluster Ready Services-managed resources
CRS-6017: Processing resource auto-start for servers: vzwc1
CRS-6016: Resource auto-start has completed for server vzwc1
CRS-6024: Completed start of Oracle Cluster Ready Services-managed resources
CRS-4123: Oracle High Availability Services has been started.
2014/03/31 22:33:53 CLSRSC-343: Successfully started Oracle clusterware stack


CRS-2672: Attempting to start 'ora.net1.network' on 'vzwc1'
CRS-2676: Start of 'ora.net1.network' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.gns.vip' on 'vzwc1'
CRS-2676: Start of 'ora.gns.vip' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.gns' on 'vzwc1'
CRS-2676: Start of 'ora.gns' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.ASMNET1LSNR_ASM.lsnr' on 'vzwc1'
CRS-2676: Start of 'ora.ASMNET1LSNR_ASM.lsnr' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.asm' on 'vzwc1'
CRS-2676: Start of 'ora.asm' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.CRSDG.dg' on 'vzwc1'
CRS-2676: Start of 'ora.CRSDG.dg' on 'vzwc1' succeeded
CRS-2791: Starting shutdown of Oracle High Availability Services-managed resources on 'vzwc1'
CRS-2673: Attempting to stop 'ora.crsd' on 'vzwc1'
CRS-2790: Starting shutdown of Cluster Ready Services-managed resources on 'vzwc1'
CRS-2673: Attempting to stop 'ora.vzwc1.vip' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.CRSDG.dg' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.cvu' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.LISTENER_SCAN3.lsnr' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.LISTENER_SCAN1.lsnr' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.LISTENER_SCAN2.lsnr' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.gns' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.oc4j' on 'vzwc1'
CRS-2677: Stop of 'ora.cvu' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.LISTENER_SCAN3.lsnr' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.scan3.vip' on 'vzwc1'
CRS-2677: Stop of 'ora.LISTENER_SCAN1.lsnr' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.scan1.vip' on 'vzwc1'
CRS-2677: Stop of 'ora.LISTENER_SCAN2.lsnr' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.scan2.vip' on 'vzwc1'
CRS-2677: Stop of 'ora.vzwc1.vip' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.scan1.vip' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.scan2.vip' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.scan3.vip' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.gns' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.gns.vip' on 'vzwc1'
CRS-2677: Stop of 'ora.gns.vip' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.oc4j' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.CRSDG.dg' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.asm' on 'vzwc1'
CRS-2677: Stop of 'ora.asm' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.ASMNET1LSNR_ASM.lsnr' on 'vzwc1'
CRS-2677: Stop of 'ora.ASMNET1LSNR_ASM.lsnr' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.ons' on 'vzwc1'
CRS-2677: Stop of 'ora.ons' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.net1.network' on 'vzwc1'
CRS-2677: Stop of 'ora.net1.network' on 'vzwc1' succeeded
CRS-2792: Shutdown of Cluster Ready Services-managed resources on 'vzwc1' has completed
CRS-2677: Stop of 'ora.crsd' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.storage' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.drivers.acfs' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.ctssd' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.gpnpd' on 'vzwc1'
CRS-2673: Attempting to stop 'ora.mdnsd' on 'vzwc1'
CRS-2677: Stop of 'ora.storage' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.asm' on 'vzwc1'
CRS-2677: Stop of 'ora.drivers.acfs' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.mdnsd' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.gpnpd' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.ctssd' on 'vzwc1' succeeded
CRS-2677: Stop of 'ora.asm' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.cluster_interconnect.haip' on 'vzwc1'
CRS-2677: Stop of 'ora.cluster_interconnect.haip' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.evmd' on 'vzwc1'
CRS-2677: Stop of 'ora.evmd' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.cssd' on 'vzwc1'
CRS-2677: Stop of 'ora.cssd' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.crf' on 'vzwc1'
CRS-2677: Stop of 'ora.crf' on 'vzwc1' succeeded
CRS-2673: Attempting to stop 'ora.gipcd' on 'vzwc1'
CRS-2677: Stop of 'ora.gipcd' on 'vzwc1' succeeded
CRS-2793: Shutdown of Oracle High Availability Services-managed resources on 'vzwc1' has completed
CRS-4133: Oracle High Availability Services has been stopped.
CRS-4123: Starting Oracle High Availability Services-managed resources
CRS-2672: Attempting to start 'ora.mdnsd' on 'vzwc1'
CRS-2672: Attempting to start 'ora.evmd' on 'vzwc1'
CRS-2676: Start of 'ora.mdnsd' on 'vzwc1' succeeded
CRS-2676: Start of 'ora.evmd' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.gpnpd' on 'vzwc1'
CRS-2676: Start of 'ora.gpnpd' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.gipcd' on 'vzwc1'
CRS-2676: Start of 'ora.gipcd' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.cssdmonitor' on 'vzwc1'
CRS-2676: Start of 'ora.cssdmonitor' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.cssd' on 'vzwc1'
CRS-2672: Attempting to start 'ora.diskmon' on 'vzwc1'
CRS-2676: Start of 'ora.diskmon' on 'vzwc1' succeeded
CRS-2789: Cannot stop resource 'ora.diskmon' as it is not running on server 'vzwc1'
CRS-2676: Start of 'ora.cssd' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.cluster_interconnect.haip' on 'vzwc1'
CRS-2672: Attempting to start 'ora.ctssd' on 'vzwc1'
CRS-2676: Start of 'ora.ctssd' on 'vzwc1' succeeded
CRS-2676: Start of 'ora.cluster_interconnect.haip' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.asm' on 'vzwc1'
CRS-2676: Start of 'ora.asm' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.storage' on 'vzwc1'
CRS-2676: Start of 'ora.storage' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.crf' on 'vzwc1'
CRS-2676: Start of 'ora.crf' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.crsd' on 'vzwc1'
CRS-2676: Start of 'ora.crsd' on 'vzwc1' succeeded
CRS-6023: Starting Oracle Cluster Ready Services-managed resources
CRS-6017: Processing resource auto-start for servers: vzwc1
CRS-2672: Attempting to start 'ora.oc4j' on 'vzwc1'
CRS-2672: Attempting to start 'ora.ons' on 'vzwc1'
CRS-2672: Attempting to start 'ora.cvu' on 'vzwc1'
CRS-2676: Start of 'ora.cvu' on 'vzwc1' succeeded
CRS-2676: Start of 'ora.ons' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.scan3.vip' on 'vzwc1'
CRS-2672: Attempting to start 'ora.scan1.vip' on 'vzwc1'
CRS-2672: Attempting to start 'ora.scan2.vip' on 'vzwc1'
CRS-2672: Attempting to start 'ora.vzwc1.vip' on 'vzwc1'
CRS-2676: Start of 'ora.scan1.vip' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.LISTENER_SCAN1.lsnr' on 'vzwc1'
CRS-2676: Start of 'ora.scan3.vip' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.LISTENER_SCAN3.lsnr' on 'vzwc1'
CRS-2676: Start of 'ora.scan2.vip' on 'vzwc1' succeeded
CRS-2672: Attempting to start 'ora.LISTENER_SCAN2.lsnr' on 'vzwc1'
CRS-2676: Start of 'ora.vzwc1.vip' on 'vzwc1' succeeded
CRS-2676: Start of 'ora.LISTENER_SCAN1.lsnr' on 'vzwc1' succeeded
CRS-2676: Start of 'ora.LISTENER_SCAN3.lsnr' on 'vzwc1' succeeded
CRS-2676: Start of 'ora.LISTENER_SCAN2.lsnr' on 'vzwc1' succeeded
CRS-2676: Start of 'ora.oc4j' on 'vzwc1' succeeded
CRS-6016: Resource auto-start has completed for server vzwc1
CRS-6024: Completed start of Oracle Cluster Ready Services-managed resources
CRS-4123: Oracle High Availability Services has been started.
2014/03/31 22:42:25 CLSRSC-325: Configure Oracle Grid Infrastructure for a Cluster ... succeeded

--验证安装

[iyunv@vzwc3 ~]# crsctl stat res -t
--------------------------------------------------------------------------------
Name           Target  State        Server                   State details
--------------------------------------------------------------------------------
Local Resources
--------------------------------------------------------------------------------
ora.ASMNET1LSNR_ASM.lsnr
               ONLINE  ONLINE       vzwc1                    STABLE
               ONLINE  ONLINE       vzwc2                    STABLE
               ONLINE  ONLINE       vzwc3                    STABLE
ora.CRSDG.dg
               ONLINE  ONLINE       vzwc1                    STABLE
               ONLINE  ONLINE       vzwc2                    STABLE
               ONLINE  ONLINE       vzwc3                    STABLE
ora.DATADG.dg
               ONLINE  ONLINE       vzwc1                    STABLE
               ONLINE  ONLINE       vzwc2                    STABLE
               ONLINE  ONLINE       vzwc3                    STABLE
ora.FRADG.dg
               ONLINE  ONLINE       vzwc1                    STABLE
               ONLINE  ONLINE       vzwc2                    STABLE
               ONLINE  ONLINE       vzwc3                    STABLE
ora.LISTENER.lsnr
               ONLINE  ONLINE       vzwc1                    STABLE
               ONLINE  ONLINE       vzwc2                    STABLE
               ONLINE  ONLINE       vzwc3                    STABLE
ora.net1.network
               ONLINE  ONLINE       vzwc1                    STABLE
               ONLINE  ONLINE       vzwc2                    STABLE
               ONLINE  ONLINE       vzwc3                    STABLE
ora.ons
               ONLINE  ONLINE       vzwc1                    STABLE
               ONLINE  ONLINE       vzwc2                    STABLE
               ONLINE  ONLINE       vzwc3                    STABLE
ora.proxy_advm
               ONLINE  ONLINE       vzwc1                    STABLE
               ONLINE  ONLINE       vzwc2                    STABLE
               ONLINE  ONLINE       vzwc3                    STABLE
--------------------------------------------------------------------------------
Cluster Resources
--------------------------------------------------------------------------------
ora.LISTENER_SCAN1.lsnr
      1        ONLINE  ONLINE       vzwc2                    STABLE
ora.LISTENER_SCAN2.lsnr
      1        ONLINE  ONLINE       vzwc3                    STABLE
ora.LISTENER_SCAN3.lsnr
      1        ONLINE  ONLINE       vzwc1                    STABLE
ora.MGMTLSNR
      1        ONLINE  ONLINE       vzwc1                    169.254.39.90 10.10.
                                                             10.1,STABLE
ora.asm
      1        ONLINE  ONLINE       vzwc1                    STABLE
      2        ONLINE  ONLINE       vzwc2                    STABLE
      3        ONLINE  ONLINE       vzwc3                    STABLE
ora.cvu
      1        ONLINE  ONLINE       vzwc1                    STABLE
ora.gns
      1        ONLINE  ONLINE       vzwc1                    STABLE
ora.gns.vip
      1        ONLINE  ONLINE       vzwc1                    STABLE
ora.mgmtdb
      1        ONLINE  ONLINE       vzwc1                    Open,STABLE
ora.oc4j
      1        ONLINE  ONLINE       vzwc1                    STABLE
ora.scan1.vip
      1        ONLINE  ONLINE       vzwc2                    STABLE
ora.scan2.vip
      1        ONLINE  ONLINE       vzwc3                    STABLE
ora.scan3.vip
      1        ONLINE  ONLINE       vzwc1                    STABLE
ora.vzwc1.vip
      1        ONLINE  ONLINE       vzwc1                    STABLE
ora.vzwc2.vip
      1        ONLINE  ONLINE       vzwc2                    STABLE
ora.vzwc3.vip
      1        ONLINE  ONLINE       vzwc3                    STABLE
--------------------------------------------------------------------------------

[iyunv@vzwc3 ~]# crsctl check cluster -all
**************************************************************
vzwc1:
CRS-4537: Cluster Ready Services is online
CRS-4529: Cluster Synchronization Services is online
CRS-4533: Event Manager is online
**************************************************************
vzwc2:
CRS-4537: Cluster Ready Services is online
CRS-4529: Cluster Synchronization Services is online
CRS-4533: Event Manager is online
**************************************************************
vzwc3:
CRS-4537: Cluster Ready Services is online
CRS-4529: Cluster Synchronization Services is online
CRS-4533: Event Manager is online
**************************************************************

[iyunv@vzwc3 ~]# olsnodes -s
vzwc1   Active
vzwc2   Active
vzwc3   Active

[grid@vzwc3 ~]$ cluvfy comp scan
Verifying scan

Checking Single Client Access Name (SCAN)...

Checking TCP connectivity to SCAN Listeners...
TCP connectivity to SCAN Listeners exists on all cluster nodes

Checking name resolution setup for "vzwc-cluster-scan.zero.zhongwc.com"...

Checking integrity of name service switch configuration file "/etc/nsswitch.conf" ...
All nodes have same "hosts" entry defined in file "/etc/nsswitch.conf"
Check for integrity of name service switch configuration file "/etc/nsswitch.conf" passed

Checking SCAN IP addresses...
Check of SCAN IP addresses passed

Verification of SCAN VIP and Listener setup passed

Verification of scan was successful.

[iyunv@vzwc3 ~]# srvctl status scan_listener
SCAN Listener LISTENER_SCAN1 is enabled
SCAN listener LISTENER_SCAN1 is running on node vzwc2
SCAN Listener LISTENER_SCAN2 is enabled
SCAN listener LISTENER_SCAN2 is running on node vzwc3
SCAN Listener LISTENER_SCAN3 is enabled
SCAN listener LISTENER_SCAN3 is running on node vzwc1

[grid@vzwc3 ~]$ lsnrctl status ASMNET1LSNR_ASM

LSNRCTL for Linux: Version 12.1.0.1.0 - Production on 31-MAR-2014 23:19:46

Copyright (c) 1991, 2013, Oracle.  All rights reserved.

Connecting to (DESCRIPTION=(ADDRESS=(PROTOCOL=IPC)(KEY=ASMNET1LSNR_ASM)))
STATUS of the LISTENER
------------------------
Alias                     ASMNET1LSNR_ASM
Version                   TNSLSNR for Linux: Version 12.1.0.1.0 - Production
Start Date                31-MAR-2014 22:58:18
Uptime                    0 days 0 hr. 21 min. 28 sec
Trace Level               off
Security                  ON: Local OS Authentication
SNMP                      OFF
Listener Parameter File   /u01/app/12.1.0/grid/network/admin/listener.ora
Listener Log File         /u01/app/grid/diag/tnslsnr/vzwc3/asmnet1lsnr_asm/alert/log.xml
Listening Endpoints Summary...
  (DESCRIPTION=(ADDRESS=(PROTOCOL=ipc)(KEY=ASMNET1LSNR_ASM)))
  (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=10.10.10.6)(PORT=1521)))
  (DESCRIPTION=(ADDRESS=(PROTOCOL=tcp)(HOST=10.10.10.5)(PORT=1521)))
Services Summary...
Service "+ASM" has 3 instance(s).
  Instance "+ASM1", status READY, has 1 handler(s) for this service...
  Instance "+ASM2", status READY, has 1 handler(s) for this service...
  Instance "+ASM3", status READY, has 2 handler(s) for this service...
The command completed successfully

[iyunv@vzwc3 ~]# srvctl status asm -detail
ASM is running on vzwc2,vzwc3,vzwc1
ASM is enabled.

[grid@vzwc2 grid]$ srvctl config asm
ASM home: /u01/app/12.1.0/grid
Password file: +CRSDG/orapwASM
ASM listener: LISTENER
ASM instance count: 3
Cluster ASM listener: ASMNET1LSNR_ASM

[grid@vzwc1 ~]$ hostname
vzwc1.zhongwc.com
[grid@vzwc1 ~]$ sqlplus / as sysasm

SQL*Plus: Release 12.1.0.1.0 Production on Mon Mar 31 23:27:33 2014

Copyright (c) 1982, 2013, Oracle.  All rights reserved.

Connected to:
Oracle Database 12c Enterprise Edition Release 12.1.0.1.0 - 64bit Production
With the Real Application Clusters and Automatic Storage Management options

SQL> col instance_name for a10
SQL> select instance_name, db_name, status from v$asm_client;

INSTANCE_N DB_NAME          STATUS
---------- ---------------- ------------------------
+ASM1      +ASM             CONNECTED
+APX1      +APX             CONNECTED
-MGMTDB    _mgmtdb          CONNECTED

[grid@vzwc1 ~]$ asmcmd lsdg
State    Type    Rebal  Sector  Block       AU  Total_MB  Free_MB  Req_mir_free_MB  Usable_file_MB  Offline_disks  Voting_files  Name
MOUNTED  EXTERN  N         512   4096  1048576     10240     6498                0            6498              0             Y  CRSDG/
MOUNTED  EXTERN  N         512   4096  1048576     30720    30582                0           30582              0             N  DATADG/
MOUNTED  EXTERN  N         512   4096  1048576     20480    20342                0           20342              0             N  FRADG/
[grid@vzwc1 ~]$ asmcmd lsdsk
Path
/dev/asm-diskb
/dev/asm-diskc
/dev/asm-diskd

[grid@vzwc2 grid]$asmcmd showclustermode
ASM cluster : Flex mode enabled

参考:

Expert Oracle RAC 12c
