| [iyunv@centos02 tools]# wget wget
[iyunv@centos02 tools]# rpm -ivh epel-release-6-8.noarch.rpm
[iyunv@centos02 tools]# yum install ganglia-gmetad.x86_64 ganglia-gmond.x86_64 ganglia-gmond-python.x86_64 -y
修改服务端配置文件
[iyunv@centos02 tools]# vim /etc/ganglia/gmetad.conf
data_source "my cluster" 172.16.80.117 172.16.80.116
gridname "MyGrid"
ganglia web的安装(基于LNMP环境)
[iyunv@centos02 tools]# tar xf ganglia-web-3.7.2.tar.gz
[iyunv@centos02 tools]# mv ganglia-web-3.7.2 /application/nginx/html/ganglia
修改ganglia web的php配置文件
[iyunv@centos02 tools]# vim /application/nginx/html/ganglia/conf_default.php
$conf['gweb_confdir'] = "/application/nginx/html/ganglia";
nginx配置
[iyunv@centos02 ganglia]# cat /application/nginx/conf/nginx.conf
worker_processes 2;
events {
worker_connections 1024;
}
http {
log_format main '$remote_addr - $remote_user [$time_local] "$request" '
'$status $body_bytes_sent "$http_referer" '
'"$http_user_agent" "$http_x_forwarded_for"';
include mime.types;
default_type application/octet-stream;
sendfile on;
keepalive_timeout 65;
server {
listen 80;
server_name www.martin.com martin.com;
location / {
root html/zabbix;
index index.php index.html index.htm;
}
location ~ .*\.(php|php5)?$ {
root html/zabbix;
fastcgi_pass 127.0.0.1:9000;
fastcgi_index index.php;
include fastcgi.conf;
}
access_log logs/access_zabbix.log main;
}
server {
listen 80;
server_name ganglia.martin.com;
location / {
root html/ganglia;
index index.php index.html index.htm;
}
location ~ .*\.(php|php5)?$ {
root html/ganglia;
fastcgi_pass 127.0.0.1:9000;
fastcgi_index index.php;
include fastcgi.conf;
}
access_log logs/access_bbs.log main;
}
###status
server{
listen 80;
server_name status.martin.org;
location / {
stub_status on;
access_log off;
}
}
}
访问测试,报错如下
Fatal error:Errors were detected in your configuration.
DWOO compiled templates directory '/application/nginx/html/ganglia/dwoo/compiled' is not writeable.
Please adjust $conf['dwoo_compiled_dir'].
DWOO cache directory '/application/nginx/html/ganglia/dwoo/cache' is not writeable.
Please adjust $conf['dwoo_cache_dir'].
in /application/nginx-1.6.3/html/ganglia/eval_conf.php on line 126
解决办法:
[iyunv@centos02 tools]# mkdir /application/nginx/html/ganglia/dwoo/compiled
[iyunv@centos02 tools]# mkdir /application/nginx/html/ganglia/dwoo/cache
[iyunv@centos02 tools]# chmod 777 /application/nginx/html/ganglia/dwoo/compiled
[iyunv@centos02 tools]# chmod 777 /application/nginx/html/ganglia/dwoo/cache
[iyunv@centos02 html]# chmod -R 777 /var/lib/ganglia/rrds
修改客户端配置文件(所有的客户端都需要做)
[iyunv@centos02 tools]# vim /etc/ganglia/gmond.conf
cluster {
name = "my cluster" #这个名字要和服务器端定义的data_source后面的名字一样
owner = "unspecified"
latlong = "unspecified"
url = "unspecified"
}
udp_send_channel {
#bind_hostname = yes # Highly recommended, soon to be default.
# This option tells gmond to use a source address
# that resolves to the machine's hostname. Without
# this, the metrics may appear to come from any
# interface and the DNS names associated with
# those IPs will be used to create the RRDs.
# mcast_join = 239.2.11.71
host = 172.16.80.117 #这里我们采用单播方式,默认是组播
port = 8649
# ttl = 1
}
udp_recv_channel {
# mcast_join = 239.2.11.71
port = 8649
# bind = 239.2.11.71
retry_bind = true
# Size of the UDP buffer. If you are handling lots of metrics you really
# should bump it up to e.g. 10MB or even higher.
# buffer = 10485760
}
|
