OCM考试中Dataguar的配置

opo

OCM中Dataguar的配置，在同一主机上实现

1、打开主数据库的logging功能
ALTER DATABASE FORCE LOGGING;
2、打开主数据库的归档功能
alter database archivelog;
3、关闭主数据库，启动到mount模式
alter database add standby logfile group 4 '/Oracle/oradata/test/sredo4.dbf' size 20m;
alter database add standby logfile group 5 '/oracle/oradata/test/sredo5.dbf' size 20m;
alter database add standby logfile group 6 '/oracle/oradata/test/sredo6.dbf' size 20m;

alter database create standby controlfile as '/oracle/oradata/std/control01.dbf';

备份主数据库的数据文件、控制文件到/oracle/oradata/std/

4、配置网络参数

监听器和TNSNAMES

主库与从库的LISTENER.ORA

LISTENER =
   (DESCRIPTION_LIST =
     (DESCRIPTION =
        (ADDRESS_LIST =
        (ADDRESS = (PROTOCOL = TCP)(HOST = db)(PORT = 1521))
        )
     )
   )

SID_LIST_LISTENER =
   (SID_LIST =
      (SID_DESC =
        (GLOBAL_DBNAME = test)
        (ORACLE_HOME = /oracle/db10g)
        (SID_NAME = test)
      )
      (SID_DESC =
        (GLOBAL_DBNAME = standby)
        (ORACLE_HOME = /oracle/db10g)
        (SID_NAME = stb)
      )
   )

主库与从库的TNSNAMES.ORA：

test =
   (DESCRIPTION =
      (ADDRESS_LIST =
         (ADDRESS = (PROTOCOL = TCP)(HOST = db)(PORT = 1521))
      )
      (CONNECT_DATA =
         (SERVER = DEDICATED)
         (SERVICE_NAME = test)
      )
   )


stb =
   (DESCRIPTION =
      (ADDRESS_LIST =
         (ADDRESS = (PROTOCOL = TCP)(HOST = db)(PORT = 1521))
      )
      (CONNECT_DATA =
         (SERVER = DEDICATED)
         (SERVICE_NAME = stb)
      )
   )

5、创建备用数据库的参数文件
create pfile from spfile;
cp inittest.ora initstb.ora

主TEST数据库创建pfile文件，添加以下参数：
注：删除一切关于MTS的参数（shared server）

DB_UNIQUE_NAME=test
LOG_ARCHIVE_CONFIG='DG_CONFIG=(test,stb)'
LOG_ARCHIVE_DEST_1='LOCATION=/oracle/arch/test VALID_FOR=(ALL_LOGFILES,ALL_ROLES) '
LOG_ARCHIVE_DEST_2='SERVICE=stb LGWR ASYNC VALID_FOR=(ONLINE_LOGFILES,PRIMARY_ROLE)  DB_UNIQUE_NAME=standby'
FAL_SERVER=stb
FAL_CLIENT=test
DB_FILE_NAME_CONVERT='/oracle/oradata/stb','/oracle/oradata/test'
LOG_FILE_NAME_CONVERT='/oracle/oradata/stb','/oracle/oradata/test'
STANDBY_FILE_MANAGEMENT=AUTO


从库STANDBY数据库修改以下Pfile内容
control_files='/oracle/oradata/stb/control01.ctl'
core_dump_dest='/oracle/admin/stb/cdump'
user_dump_dest='/oracle/admin/stb/udump'
background_dump_dest='/oracle/admin/stb/bdump'

以下为添加的参数
DB_UNIQUE_NAME=stb
LOG_ARCHIVE_CONFIG='DG_CONFIG=(stb,test)'
LOG_ARCHIVE_DEST_1='LOCATION=/oracle/arch/stb VALID_FOR=(ALL_LOGFILES,ALL_ROLES) '
LOG_ARCHIVE_DEST_2='SERVICE=test LGWR ASYNC VALID_FOR=(ONLINE_LOGFILES,PRIMARY_ROLE) DB_UNIQUE_NAME=test'
FAL_SERVER=test
FAL_CLIENT=stb
DB_FILE_NAME_CONVERT='/oracle/oradata/test','/oracle/oradata/stb'
LOG_FILE_NAME_CONVERT='/oracle/oradata/test','/oracle/oradata/stb'
STANDBY_FILE_MANAGEMENT=AUTO


6、启动从库到mount，并把数据库变成recover managed状态，注意过程从库的警告日志文件：
SQL>startup mount；

ALTER DATABASE RECOVER MANAGED STANDBY DATABASE DISCONNECT FROM SESSION;

7、启动主库数据库，切换日志，并观察主从库的警告日志文件，如果归档成功，说明配置成功：
SQL>alter system switch logfile;


8、主从角色的切换，主库查看状态：
SQL> SELECT SWITCHOVER_STATUS FROM V$DATABASE;
SWITCHOVER_STATUS
-----------------
TO STANDBY

SQL>alter database commit to switchover to standby;

9、从库操作：
SQL>alter database commit to switchover to primary;

10、在主库上（注意此时的角色转换）切换日志，如果主从库归档成功，说明Standby配置成功。
