Nagios结合pnp4nagios出图

134564

系统CentOS6.5 64位
nagios服务已经安装完成，下面先安装rrdtool，http://oss.oetiker.ch/rrdtool/
yum install  libjpeg-devel libpng-devel pango* libart_lgpl-devel pango-devel* cairo-devel* libxml2-devel libjpeg-devel libpng-devel gd-devel perl-GD libtoul-ltdl-devel rrdtool-perl perl-devel perl-ExtUtils-Embed
tar -xzf rrdtool-1.4.9.tar.gz
cd rrdtool-1.4.9
./configure --prifix=/usr/local/rrdtool
make
make install
cd ..

安装pnp4nagios http://www.pnp4nagios.org/

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17

tar -xzf pnp4nagios-0.6.24.tar.gz cd pnp4nagios-0.6.24 ls /usr/local/pnp ./configure --with-nagios-user=nagios --with-nagios-group=nagios --with-rrdtool=/usr/local/rrdtool/bin/rrdtool make all make install make install-webconf   make install-config   make install-init    cd /usr/local/nagios/etc/pnp/ cp process_perfdata.cfg-sample process_perfdata.cfg cp npcd.cfg-sample npcd.cfg cp rra.cfg-sample rra.cfg chown -R nagios:nagios /usr/local/nagios/etc/pnp vim /usr/local/nagios/etc/pnp/process_perfdata.cfg LOG_LEVEL = 2 #开启调试模式，不调试就不用开启

#PNP的五种模式 Synchronous Mode、Bulk Mode、Bulk Mode with NPCD、Bulk Mode with npcdmod、Gearman Mode http://docs.pnp4nagios.org/pnp-0.6/modes

#下面是Bulk Mode with NPCD模式配置
cd /usr/local/nagios/etc/objects/

1 2 3 4 5

vim commands.cfg # 'process-host-perfdata' command definition #注释process-host-perfdata和process-service-perfdata define command{ command_name process-service-perfdata-file

#启动npcd服务
/usr/local/pnp4nagios/bin/npcd -d -f /usr/local/pnp4nagios/etc/npcd.cfg

1 2 3 4 5 6 7 8 9 10 11 12

vim /usr/local/nagios/etc/nagios.cfg process_performance_data=1   service_perfdata_file=/usr/local/pnp4nagios/var/service-perfdata   service_perfdata_file_template=DATATYPE::SERVICEPERFDATA        TIMET::$TIMET$        HOSTNAME::$HOSTNAME$        SERVICEDESC::$SERVICEDESC$        SERVICEPERFDATA::$SERVICEPERFDATA$        SERVICECHECKCOMMAND::$SERVICECHECKCOMMAND$        HOSTSTATE::$HOSTSTATE$        HOSTSTATETYPE::$HOSTSTATETYPE$        SERVICESTATE::$SERVICESTATE$        SERVICESTATETYPE::$SERVICESTATETYPE$   service_perfdata_file_mode=a   service_perfdata_file_processing_interval=15   service_perfdata_file_processing_command=process-service-perfdata-file host_perfdata_file=/usr/local/pnp4nagios/var/host-perfdata   host_perfdata_file_template=DATATYPE::HOSTPERFDATA        TIMET::$TIMET$        HOSTNAME::$HOSTNAME$        HOSTPERFDATA::$HOSTPERFDATA$        HOSTCHECKCOMMAND::$HOSTCHECKCOMMAND$        HOSTSTATE::$HOSTSTATE$        HOSTSTATETYPE::$HOSTSTATETYPE$   host_perfdata_file_mode=a   host_perfdata_file_processing_interval=15   host_perfdata_file_processing_command=process-host-perfdata-file

1 2 3 4 5 6 7 8 9 10 11 12 13

vim localhost.cfg define host{         use                     linux-server,host-pnp #修改这里         host_name               localhost         alias                   localhost         address                 127.0.0.1         } define service{         use                             local-service,service-pnp #需要画图的都加上service-pnp               host_name                       localhost         service_description             PING         check_command                   check_ping!100.0,20%!500.0,60%         }

1 2 3 4 5 6 7 8 9 10 11 12 13

vim templates.cfg define host { name       host-pnp register   0 action_url /pnp4nagios/graph?host=$HOSTNAME$&srv=_HOST_ process_perf_data 1 } define service { name       service-pnp register   0 action_url /pnp4nagios/graph?host=$HOSTNAME$&srv=$SERVICEDESC$ process_perf_data 1 }

配置完成，将nagios重启
service nagios restart



到pnp4nagios-0.6.24解压目录下
cp pnp4nagios-0.6.24/contrib/ssi/status-header.ssi /usr/local/nagios/share/ssi/

1 2 3 4 5 6 7 8 9 10 11 12 13

vim /usr/local/nagios/etc/objects/templates.cfg   define host {    name       host-pnp    register   0 action_url /pnp4nagios/graph?host=$HOSTNAME$&srv=_HOST_' class='tips' rel='/pnp4nagios/popup?host=$HOSTNAME$&srv=_HOST_    process_perf_data 1 } define service {    name       service-pnp    register   0 action_url /pnp4nagios/graph?host=$HOSTNAME$&srv=$SERVICEDESC$' class='tips' rel='/pnp4nagios/popup?host=$HOSTNAME$&srv=$SERVICEDESC$      process_perf_data 1 }

cd /usr/local/pnp4nagios/etc/pages
cp web_traffic.cfg-sample web_traffic.cfg
