Centos 6.7 安装smokeping （最完整教程）

xiang8

　　本教程需要的源码包一并上传了，届时可以直接上传到linux系统里面！
　　需要编译的fping、echoping、smokeping源码包，链接：https://pan.baidu.com/s/1c27XYjI 密码：e54o
　　
系统：centos 6.7
　　1、安装依赖包：
yum install -y perl perl-Net-Telnet perl-Net-DNS perl-LDAP perl-libwww-perl perl-IO-Socket-SSL perl-Socket6 perl-Time-HiRes perl-ExtUtils-MakeMaker rrdtool rrdtool-perl curl httpd httpd-devel gcc make wget libxml2-devel libpng-devel glib pango pango-devel freetype freetype-devel fontconfig cairo cairo-devel libart_lgpl libart_lgpl-devel popt popt-devel libidn libidn-devel
　　rz上传三个源码包（上文已包含）
2、解压、编译安装fping
tar xf fping-3.10.tar.gz
cd fping-3.10
./configure
make && make install
　　3、解压、编译安装echoping
tar xf echoping-6.0.2.tar.gz
cd echoping-6.0.2
./configure
make && make install
　　4、解压、编译安装smokeping
tar xf smokeping-2.6.9.tar.gz
cd smokeping-2.6.9
./setup/build-perl-modules.sh /usr/local/smokeping/thirdparty
./configure --prefix=/usr/local/smokeping
/usr/bin/gmake install
　　5、配置 smokeping
cd /usr/local/smokeping/
mkdir cache data var
touch /var/log/smokeping.log
chown apache:apache cache data var
chown apache:apache /var/log/smokeping.log
chmod 600 /usr/local/smokeping/etc/smokeping_secrets.dist
cd /usr/local/smokeping/htdocs
mv smokeping.fcgi.dist smokeping.fcgi
cd /usr/local/smokeping/etc
mv config.dist config
　　6、更改配置文件
vim /usr/local/smokeping/etc/config
主要修改如下内容：
#cgiurl = http://some.url/smokeping.cgi
cgiurl = http://10.0.0.62/smokeping.cgi
　　*** Database ***
#step = 300
step = 60 #此处建议改为 60 ， 一分钟采集一次数据
pings = 20
　　
7、编辑apache配置文件
vim /etc/httpd/conf/httpd.conf
最后边添加如下：
　　Alias /cache "/usr/local/smokeping/cache/"
Alias /cropper "/usr/local/smokeping/htdocs/cropper/"
Alias /smokeping "/usr/local/smokeping/htdocs/smokeping.fcgi"
<Directory "/usr/local/smokeping">
AllowOverride None
Options All
AddHandler cgi-script .fcgi .cgi
Order allow,deny
Allow from all
DirectoryIndex smokeping.fcgi
</Directory>
　　
8、图像浏览界面的中文支持
安装字体
yum -y install wqy-zenhei-fonts.noarch
　　编辑smokeping的配置文件
vim /usr/local/smokeping/etc/config
　　第50行添加
　　charset = utf-8 #添加此行
　　编辑Graphs.pm
vim /usr/local/smokeping/lib/Smokeping/Graphs.pm
#第147行下边插入下边一行
　　'--font TITLE:20:"WenQuanYi Zen Hei Mono"',
　　
　　9、##########测试数据可自定义##########
　　config 配置文件的最后边
vim /usr/local/smokeping/etc/config
　　
+ Other
menu = 三大网络监控
title = 监控统计
++ dianxin
menu = 电信网络监控
title = 电信网络监控列表
host = /Other/dianxin/dianxin-bj /Other/dianxin/dianxin-hlj /Other/dianxin/dianxin-tj /Other/dianxin/dianxin-sc /Other/dianxin/dianxin-sh /Other/dianxin/dianxin-gz
+++ dianxin-bj
menu = 北京电信
title = 北京电信
alerts = someloss
host = 202.96.199.133
+++ dianxin-hlj
menu = 黑龙江电信
title = 黑龙江电信
alerts = someloss
host = 219.147.198.242
+++ dianxin-tj
menu = 天津电信
title = 天津电信
alerts = someloss
host = 219.150.32.132
+++ dianxin-sc
menu = 四川电信
title = 四川电信
alerts = someloss
host = 61.139.2.69
+++ dianxin-sh
menu = 上海电信
title = 上海电信
alerts = someloss
host = 116.228.111.118
+++ dianxin-gz
menu = 广东电信
title = 广东电信
alerts = someloss
host = 113.111.211.22
++ liantong
menu = 联通网络监控
title = 联通网络监控列表
host = /Other/liantong/liantong-bj /Other/liantong/liantong-hlj /Other/liantong/liantong-tj /Other/liantong/liantong-sc /Other/liantong/liantong-sh /Other/liantong/liantong-gz
+++ liantong-bj
menu = 北京联通
title = 北京联通
alerts = someloss
host = 61.135.169.121
+++ liantong-hlj
menu = 黑龙江联通
title = 黑龙江联通
alerts = someloss
host = 202.97.224.69
+++ liantong-tj
menu = 天津联通
title = 天津联通
alerts = someloss
host = 202.99.96.68
+++ liantong-sc
menu = 四川联通
title = 四川联通
alerts = someloss
host = 119.6.6.6
+++ liantong-sh
menu = 上海联通
title = 上海联通
alerts = someloss
host = 210.22.84.3
+++ liantong-gz
menu = 广东联通
title = 广东联通
alerts = someloss
host = 221.5.88.88
++ yidong
menu = 移动网络监控
title = 移动网络监控列表
host = /Other/yidong/yidong-bj /Other/yidong/yidong-hlj /Other/yidong/yidong-tj /Other/yidong/yidong-sc /Other/yidong/yidong-sh /Other/yidong/yidong-gz
+++ yidong-bj
menu = 北京移动
title = 北京移动
alerts = someloss
host = 221.130.33.52
+++ yidong-hlj
menu = 黑龙江移动
title = 黑龙江移动
alerts = someloss
host = 211.137.241.35
+++ yidong-tj
menu = 天津移动
title = 天津移动
alerts = someloss
host = 211.137.160.5
+++ yidong-sc
menu = 四川移动
title = 四川移动
alerts = someloss
host = 218.201.4.3
+++ yidong-sh
menu = 上海移动
title = 上海移动
alerts = someloss
host = 117.131.19.23
+++ yidong-gz
menu = 广东移动
title = 广东移动
alerts = someloss
host = 211.136.192.6
　　
　　10、smokeping的默认配置文件110行的fping安装目录与此次安装目录不相符需修改！
　　vim /usr/local/smokeping/etc/config
　　#第110更改fping的目录为
binary = /usr/local/sbin/fping
　　
　　11、启动apache和smokeping&设置环境变量
/etc/init.d/httpd start
/usr/local/smokeping/bin/smokeping
　　echo 'export PATH=/usr/local/smokeping/bin/:$PATH' >> /etc/profile
