【openstack N版】——云主机调整大小\冷迁移

hx0011yy

一.先决条件
　　云主机冷迁移，即：将一台云主机从一个计算节点上，迁移到另外一个计算节点上。因为环境原因，所以我们需要准备两个计算节点。

1.1准备环境
　　在控制节点上，安装一个计算节点



#在控制节点安装nova-compute
[iyunv@linux-node1 ~]# yum install openstack-nova-compute –y
#在控制节点安装neutron及其组件
[iyunv@linux-node1 ~]# yum install openstack-neutron-linuxbridge ebtables ipset –y
1.2修改nova配置文件



#修改配置文件
[iyunv@linux-node1 ~]# vim /etc/nova/nova.conf
#配置VNC连接地址，打开注释
novncproxy_base_url=http://192.168.56.11:6080/vnc_auto.html
1.3启动nova-compute服务



#允许开机自启
[iyunv@linux-node1 ~]# systemctl enable libvirtd.service openstack-nova-compute.service
#启动服务
[iyunv@linux-node1 ~]# systemctl start libvirtd.service openstack-nova-compute.service
二.配置调整大小\冷迁移

2.1编辑nova配置文件（控制节点）



#编辑nova配置文件
[iyunv@linux-node1 ~]# vinm /etc/nova/nova.conf
#将false改为true并打开注释
allow_resize_to_same_host=true
#打开注释
scheduler_default_filters=RetryFilter,AvailabilityZoneFilter,RamFilter,DiskFilter,ComputeFilter,ComputeCapabilitiesFilter,ImagePropertiesFilter,ServerGroupAntiAffinityFilter,ServerGroupAffinityFilter
2.2重启nova控制节点



#重启服务
[iyunv@linux-node1 ~]# systemctl restart openstack-nova-api.service \
openstack-nova-consoleauth.service openstack-nova-scheduler.service \
openstack-nova-conductor.service openstack-nova-novncproxy.service
2.3修改计算节点nova配置文件



#编辑nova配置文件
[iyunv@linux-node2 ~]# vinm /etc/nova/nova.conf
#将false改为true并打开注释
allow_resize_to_same_host=true
#打开注释
scheduler_default_filters=RetryFilter,AvailabilityZoneFilter,RamFilter,DiskFilter,ComputeFilter,ComputeCapabilitiesFilter,ImagePropertiesFilter,ServerGroupAntiAffinityFilter,ServerGroupAffinityFilter
2.4重启nova计算节点



[iyunv@linux-node2 ~]# systemctl start libvirtd.service openstack-nova-compute.service
三.创建秘钥对

3.1允许nova用户登录



#查看nova用户状态
[iyunv@linux-node1 ~]# cat /etc/passwd|grep nova
nova:x:162:162:OpenStack Nova Daemons:/var/lib/nova:/sbin/nologin
#修改nova登录bash
[iyunv@linux-node1 ~]# usermod -s /bin/bash nova
#查看修改后内容
[iyunv@linux-node1 ~]# cat /etc/passwd|grep nova
nova:x:162:162:OpenStack Nova Daemons:/var/lib/nova:/bin/bash
#给nova用户创建密码
[iyunv@linux-node1 ~]# passwd nova
Changing password for user nova.
New password: nova
BAD PASSWORD: The password is shorter than 8 characters
Retype new password: nova
passwd: all authentication tokens updated successfully.

3.2修改另一台计算节点



#查看nova用户状态
[iyunv@linux-node2 ~]# cat /etc/passwd|grep nova
nova:x:162:162:OpenStack Nova Daemons:/var/lib/nova:/sbin/nologin
#修改nova登录bash
[iyunv@linux-node2 ~]# usermod -s /bin/bash nova
#查看修改后内容
[iyunv@linux-node2 ~]# cat /etc/passwd|grep nova
nova:x:162:162:OpenStack Nova Daemons:/var/lib/nova:/bin/bash
#给nova用户创建密码
[iyunv@linux-node2 ~]# passwd nova
Changing password for user nova.
New password: nova
BAD PASSWORD: The password is shorter than 8 characters
Retype new password: nova
passwd: all authentication tokens updated successfully.
3.3切换nova用户创建秘钥对



#切换用户
[iyunv@linux-node1 ~]# su - nova
#创建秘钥对
-bash-4.2$ ssh-keygen -t rsa -P '' -f ~/.ssh/id_dsa >/dev/null 2>&1
3.4另一台计算节点操作



#切换用户
[iyunv@linux-node2 ~]# su - nova
#创建秘钥对
-bash-4.2$ ssh-keygen -t rsa -P '' -f ~/.ssh/id_dsa >/dev/null 2>&1
3.5互相发送公钥



#在node1上给node2发送公钥
-bash-4.2$ ssh-copy-id -i .ssh/id_dsa.pub nova@192.168.56.12
#在node2上给node1发送公钥
-bash-4.2$ ssh-copy-id -i .ssh/id_dsa.pub nova@192.168.56.11
3.6测试是否可以面秘钥登录



-bash-4.2$ ssh 192.168.56.12
-bash-4.2$ ssh 192.168.56.11
四.调整云主机大小

五.云主机冷迁移
