COMMAND PID USER FD TYPE DEVICE> puppetmas 4750 puppet 7u IPv4 28000 0t0 TCP *:8140 (LISTEN) 3、安装客户端： xuegod64.cn 1）安装ruby openssl openssl-devel：
[root@xuegod63 ~]# scp facter-1.6.7.tar.gz puppet-2.7.13.tar.gz 192.168.1.64:/root
[root@xuegod64 ~]# yum install openssl openssl-devel
[root@xuegod64 ~]# yum install ruby -y 2）安装：facter-1.6.7.tar.gz
[root@xuegod64 ~]# tar zxvf facter-1.6.7.tar.gz
[root@xuegod64 ~]# cd facter-1.6.7
[root@xuegod64 facter-1.6.7]# ruby install.rb 3）安装：puppet
[root@xuegod64 ~]# tar zxvf puppet-2.7.13.tar.gz
[root@xuegod64 ~]# cd puppet-2.7.13
[root@xuegod64 puppet-2.7.13]# ruby install.rb 4）复制配置文件：
[root@xuegod64 puppet-2.7.13]# cp conf/namespaceauth.conf /etc/puppet/
[root@xuegod64 puppet-2.7.13]# cp conf/redhat/puppet.conf /etc/puppet/ 5）设置开机启动脚本：
[root@xuegod64 puppet-2.7.13]# cp conf/redhat/client.init /etc/init.d/puppet
[root@xuegod64 puppet-2.7.13]# chmod +x /etc/init.d/puppet
[root@xuegod64 puppet-2.7.13]# chkconfig puppet on 6）配置xuegod64 puppet配置文件：指定puppetmaster 主机名 和 客户端证书名
[root@xuegod64 puppet-2.7.13]# vim /etc/puppet/puppet.conf # 插入以下红色内容
[main]
# The Puppet log directory.
# The default value is '$vardir/log'.
logdir = /var/log/puppet
# Where Puppet PID files are kept.
# The default value is '$vardir/run'.
rundir = /var/run/puppet
# Where SSL certificates are kept.
# The default value is '$confdir/ssl'.
ssldir = $vardir/ssl
[agent]
# The file in which puppetd stores a list of the> # associated with the retrieved configuratiion. Can be loaded in
# the separate ``puppet`` executable using the ``--loadclasses``
# option.
# The default value is '$confdir/classes.txt'.
classfile = $vardir/classes.txt
server = xuegod63.cn
certname = xuegod64.cn
# Where puppetd caches the local configuration. An
# extension indicating the cache format is added automatically.
# The default value is '$confdir/localconfig'.
localconfig = $vardir/localconfig
注：
server = xuegod63.cn #指定puppetmaster 主机名
certname = xuegod64.cn #客户端证书名 7）启动服务
[root@xuegod64 puppet-2.7.13]# puppetmasterd --mkusers #生成一下用户
[root@xuegod64 puppet-2.7.13]# /etc/init.d/puppet start
[root@xuegod64 puppet-2.7.13]# netstat -antup | grep 8140
tcp 0 0 0.0.0.0:8140 0.0.0.0:* LISTEN 2829/ruby
注：发现服务器和客户端都启动8140端口
[root@xuegod63 ~]# netstat -antup | grep 8140
tcp 0 0 0.0.0.0:8140 0.0.0.0:* LISTEN 4750/ruby 4、签名证书： 客户端xuegod64找xuegod63签名 1）Xuegod64 发送请求： 生成证书请求文件
[root@xuegod64 puppet-2.7.13]# puppetd --test --server xuegod63.cn
err: Could not retrieve catalog from remote server: SSL_connect returned=1 errno=0 state=SSLv3 read server certificate B: certificate verify failed. This is often because the time is out of sync on the server or client
warning: Not using cache on failed catalog
err: Could not retrieve catalog; skipping run
err: Could not send report: SSL_connect returned=1 errno=0 state=SSLv3 read server certificate B: certificate verify failed. This is often because the time is out of sync on the server or client 出了错，解决方法： 一些文件不是证书签名的文件
[root@xuegod64 puppet-2.7.13]# rm -rf /var/lib/puppet/ssl/*
[root@xuegod64 puppet-2.7.13]# puppetd --test --server xuegod63.cn
[root@xuegod64 puppet-2.7.13]# echo $? #返回为1，没有问题。
1 2）xuegod63查看有哪些服务器证书请求文件
[root@xuegod63 puppet-2.7.13]# puppetca --list #查看哪些服务器申请了证书签名。
xuegod64.cn (DB:28:A7:03:C1:B5:55:4E:68:9E:07:0E:91:4D:7C:CB) 3）对请求文件进行签名
[root@xuegod63 puppet-2.7.13]# puppetca -s xuegod64.cn #只签名某个客户端。服务器端对 -a表示对所有的请求文件进行签名，xuegod64签名
notice: Signed certificate request for xuegod64.cn
notice: Removing file Puppet::SSL::CertificateRequest xuegod64.cn at '/var/lib/puppet/ssl/ca/requests/xuegod64.cn.pem'
[root@xuegod63 puppet-2.7.13]# puppetca -s -a # 对所有客户端全部签名
No waiting certificate requests to sign
[root@xuegod63 puppet-2.7.13]# ls /var/lib/puppet/ssl/ca/requests/ #空的，没有任何文件
[root@xuegod63 puppet-2.7.13]# ls /var/lib/puppet/ssl/ca/signed/
xuegod63.cn.pem xuegod63.pem xuegod64.cn.pem 4）查看证书签名， 前面有+号，表示已经签名成功
[root@xuegod63 puppet-2.7.13]# puppetca -a --list
+ xuegod63.cn (24:49:4F:DC:0B:55:CD:50:F9:A6:D0:F9:BA:56:A1:D6) (alt names: DNS:puppet, DNS:puppet.cn, DNS:xuegod63.cn)
+ xuegod64.cn (D1:2D:D4:95:38:46:F0:B4:A8:7E:58:5D:ED:89:35:84) 服务器签名过的证书存放位置
[root@xuegod63 puppet-2.7.13]# ls /var/lib/puppet/ssl/ca/signed/* #服务器签名过的证书存放位置
/var/lib/puppet/ssl/ca/signed/xuegod63.cn.pem
/var/lib/puppet/ssl/ca/signed/xuegod64.cn.pem 5）xuegod64重启服务器，获得可用的新CA证书，并使用新的CA证书和服务器端通信：
[root@xuegod64 puppet-2.7.13]# ls /var/lib/puppet/ssl/certs/
ca.pem
[root@xuegod64 puppet-2.7.13]# /etc/init.d/puppet restart
[root@xuegod64 puppet-2.7.13]# ls /var/lib/puppet/ssl/certs/
ca.pem xuegod64.cn.pem
#可看到证书，说明客户端和服务器端正常通信了。 ============================================================ 5、自动运维实例： 实战1，通过puppet远程在xuegod64的/tmp目录下自动创建一个文件test.txt，并写入内容：Welconme 方法一： 1）xuegod63服务端配置：
[root@xuegod63 puppet-2.7.13]# vim /etc/puppet/manifests/site.pp
[root@xuegod63 puppet-2.7.13]# cat /etc/puppet/manifests/site.pp
node default{
file { "/tmp/test.txt":
content=> "this is a test file";
}
}
[root@xuegod63 puppet-2.7.13]# /etc/init.d/puppetmaster restart 2）测试客户端能否自动创建文件
方法1 通过重启puppet客户端服务，来执行脚本
[root@xuegod64 puppet-2.7.13]# /etc/init.d/puppet restart
[root@xuegod64 puppet-2.7.13]# cat /tmp/test.txt
this is a test file 方法2： 1）同步临时生效
[root@xuegod64 puppet-2.7.13]# puppetd --test --server xuegod63.cn
info: Caching catalog for xuegod64.cn
info: Applying configuration version '1429357828'
notice: Finished catalog run in 0.10 seconds
[root@xuegod64 puppet-2.7.13]# cat /tmp/test.txt
this is a test file 方法3：等30分钟后自己同步。 实例2： 文件分发。
要把server服务器上/opt目录下的a.txt（apache-4.1.12.rpm）发布至client服务器的/opt目录下，文件名不变。 注意：分发文件时，不要用/root ，会有权限问题。 1）xuegod63配置：
[root@xuegod63 ~]# cp /etc/hosts /opt/a.txt
[root@xuegod63 ~]# vim /etc/puppet/fileserver.conf #在文件最后，追加以下内容
[files]
path /opt/
allow 192.168.1.0/24
注： [files] #名字，可以随便写 2）指定客户端要执行的操作：
[root@xuegod63 ~]# vim /etc/puppet/manifests/site.pp
[root@xuegod63 ~]# cat /etc/puppet/manifests/site.pp #添加红色内容
node default{
file { "/tmp/test.txt":
content=> "this is a test file";
}
file { "/opt/a.txt":
source => "puppet://$puppetserver/files/a.txt",
#//xuegod63.cn//opt/a.txt
}
}
注：
file { "/opt/a.txt": #指分发到客户端的路径
source => "puppet://$puppetserver/files/a.txt", 中的files要和/etc/puppet/fileserver.conf中定义的名字一样。 注：修改site.pp 文件后，服务端不需要重新启动服务。 3）同步临时生效
[root@xuegod64 puppet-2.7.13]# puppetd --test --server xuegod63.cn
info: Caching catalog for xuegod64.cn
info: Applying configuration version '1418651351'
notice: /Stage[main]//Node[default]/File[/opt/a.txt]/ensure: defined content as '{md5}e7d6d91a44650a85573b0cd47f2c1647'
notice: Finished catalog run in 0.46 seconds
[root@xuegod64 puppet-2.7.13]# ls /opt/ #查看
a.txt
[root@xuegod64 puppet-2.7.13]# cat /opt/a.txt
127.0.0.1 localhost localhost.localdomain localhost4 localhost4.localdomain4
::1 localhost localhost.localdomain localhost6 localhost6.localdomain6
192.168.1.63 xuegod63.cn
192.168.1.64 xuegod64.cn 实战3： 自动修改文件属性 1）xuegod63编写脚本配置
[root@xuegod64 ~]# ll /opt/a.txt
-rw-r--r-- 1 root root 210 10月 22 16:31 /opt/a.txt
[root@xuegod63 ~]# cat /etc/puppet/manifests/site.pp
node default{
file { "/tmp/test":
content=> "this is a test file";
}
file { "/opt/a.txt":
source => "puppet://$puppetserver/files/a.txt",
owner => "puppet",
group => "puppet",
mode => 777,
}
}
注：需要将上一个实验的代码删掉 2）同步临时生效测试：
[root@xuegod64 puppet-2.7.13]# puppetd --test --server xuegod63.cn
info: Caching catalog for xuegod64.cn
info: Applying configuration version '1418651544'
notice: /Stage[main]//Node[default]/File[/opt/a.txt]/owner: owner changed 'root' to 'puppet'
notice: /Stage[main]//Node[default]/File[/opt/a.txt]/group: group changed 'root' to 'puppet'
notice: /Stage[main]//Node[default]/File[/opt/a.txt]/mode: mode changed '0644' to '0777'
notice: Finished catalog run in 0.30 seconds
[root@xuegod64 puppet-2.7.13]# ll /opt/a.txt
-rwxrwxrwx 1 puppet puppet 213 Dec 15 21:49 /opt/a.txt 例4： server端让client端自动执行shell脚本或命令
通过puppet分发执行shell脚本，然后在客户端的/opt目录下执行test.sh脚本，该脚本执行后，会在/tmp目录创建一个testfile文件。 1）编辑测试脚本
[root@xuegod63 ~]# vim /opt/test.sh
#!/bin/bash
/bin/touch /tmp/testfile 2）编辑脚本
[root@xuegod63 opt]#vim /etc/puppet/manifests/site.pp #写入以下红色标记内容
node default{
file { "/tmp/test":
content=> "this is a test file";
}
file { "/opt/a.txt":
source => "puppet://$puppetserver/files/a.txt",
owner => "puppet",
group => "puppet",
mode => 777,
}
file { "/opt/test.sh":
source => "puppet://$puppetserver/files/test.sh",
owner => "puppet",
group => "puppet",
mode => 755,
}
exec { "exec-mkdir":
cwd => "/opt",
command => "sh /opt/test.sh",
user => "puppet",
path => "/usr/local/sbin:/usr/local/bin:/sbin:/bin:/usr/sbin:/usr/bin",
}
}
注： 不用重启服务器的 3）同步测试：
[root@xuegod64 puppet-2.7.13]#puppetd --test --server xuegod63.cn
info: Caching catalog for xuegod64.cn
info: Applying configuration version '1418651975'
notice: /Stage[main]//Node[default]/File[/opt/test.sh]/ensure: defined content as '{md5}d68e2194d349dcc3f1990a0ce37dcf1a'
notice: /Stage[main]//Node[default]/Exec[exec-mkdir]/returns: executed successfully
notice: Finished catalog run in 1.85 seconds
[root@xuegod64 puppet-2.7.13]# ls /tmp/testfile
/tmp/testfile
[root@xuegod64 puppet-2.7.13]# ll /opt/
total 8
-rwxrwxrwx 1 puppet puppet 213 Dec 15 21:49 a.txt
-rwxr-xr-x 1 puppet puppet 37 Dec 15 21:59 test.sh 例5：客户端自动执行服务的启动及关闭：
可以通过puppet对一些服务进行重启，状态等操作。puppet是通过service命令操作的。所以，只能针对在/etc/init.d/目录下的服务 实例：把客户端xuegod64的vsftpd服务关闭，并把nfs服务启动 1）准备环境：
[root@xuegod64 ~]# rpm -ivh /mnt/Packages/vsftpd-2.2.2-6.el6_0.1.x86_64.rpm
[root@xuegod64 ~]# service vsftpd start #为了实现远程关闭服务，所以这里先开着
[root@xuegod64 ~]#service nfs stop
[root@xuegod64 ~]# service vsftpd status
[root@xuegod64 ~]#service nfs status 2）配图manifests菜单，配置客户端如何执行：
[root@xuegod63 opt]# cat /etc/puppet/manifests/site.pp #添加红色标记内容
node default{
file { "/tmp/test":
content=> "this is a test file";
}
file { "/opt/a.txt":
source => "puppet://$puppetserver/files/a.txt",
owner => "puppet",
group => "puppet",
mode => 777,
}
file { "/opt/test.sh":
source => "puppet://$puppetserver/files/test.sh",
owner => "puppet",
group => "puppet",
mode => 755,
}
exec { "exec-mkdir":
cwd => "/opt",
command => "sh /opt/test.sh",
user => "puppet",
path => "/usr/local/sbin:/usr/local/bin:/sbin:/bin:/usr/sbin:/usr/bin",
}
service { vsftpd":
ensure => stopped;
"nfs":
ensure => running;
}
} 3）xuegod64 测试：
[root@xuegod64 ~]#puppetd --test --server xuegod63.cn
[root@xuegod64 ~]# service vsftpd status
vsftpd is stopped
[root@xuegod64 ~]# service nfs status
rpc.svcgssd is stopped
rpc.mountd (pid 8896) is running...
nfsd (pid 8893 8892 8891 8890 8889 8888 8887 8886) is running...
rpc.rquotad (pid 8880) is running... 实战6：修改同步时间
修改puppet 客户端默认连接puppetmaster的时间 默认puppet 客户端每隔30分钟连接到puppetmaster， 同步一次配置文件 现在修改为1分钟.同步一次。 1）修改配置文件
[root@xuegod64 ~]# cat /etc/puppet/puppet.conf #添加以下红色标记内容
[main]
# The Puppet log directory.
# The default value is '$vardir/log'.
logdir = /var/log/puppet
# Where Puppet PID files are kept.
# The default value is '$vardir/run'.
rundir = /var/run/puppet
# Where SSL certificates are kept.
# The default value is '$confdir/ssl'.
ssldir = $vardir/ssl
[agent]
# The file in which puppetd stores a list of the> # associated with the retrieved configuratiion. Can be loaded in
# the separate ``puppet`` executable using the ``--loadclasses``
# option.
# The default value is '$confdir/classes.txt'.
classfile = $vardir/classes.txt
server = xuegod63.cn
certname = xuegod64.cn
runinterval = 60 #同步时间间隔默认为妙
# Where puppetd caches the local configuration. An
[root@xuegod64 ~]# /etc/init.d/puppet restart
[root@xuegod64 ~]# rm -rf /opt/*
[root@xuegod64 ~]# ls /opt/ 2）测试：等待1分钟后再查看。
[root@xuegod64 ~]# ls /opt/ #发现执行了site.pp中内容
a.txt test.sh
