Zabbix 监控TCP的SYN,establised

blueice

　　1、在 agent 端建立脚本，并赋予 zabbix 执行权限
　　#!/bin/bash
　　# Script to fetch Netstat statuses for tribily monitoring systems
　　# Author: hanxiao2100@qq.com
　　# License: GPLv2
　　# Set Variables
　　

　　# Functions to return tcp stats
　　function tcp {
　　netstat -n | grep tcp | wc -l
　　}
　　

　　function udp {
　　netstat -n | grep udp | wc -l
　　}
　　

　　function icmp {
　　netstat -n | grep icmp | wc -l
　　}
　　

　　function syn {
　　netstat -n | grep SYN | wc -l
　　}
　　function timewait {
　　netstat -n | grep TIME_WAIT | wc -l
　　}
　　function established {
　　netstat -n | grep ESTABLISHED | wc -l
　　}
　　function close {
　　netstat -n | grep CLOSE | wc -l
　　}
　　# Run the requested function
　　$1
　　

　　2、添加zabbix_agent用户参数
　　# Monitor Network status
　　UserParameter=network.tcp,/usr/local/zabbix_agent/etc/scripts/networkStatus tcp
　　UserParameter=network.udp,/usr/local/zabbix_agent/etc/scripts/networkStatus udp
　　UserParameter=network.icmp,/usr/local/zabbix_agent/etc/scripts/networkStatus icmp
　　UserParameter=network.tcp.syn,/usr/local/zabbix_agent/etc/scripts/networkStatus syn
　　UserParameter=network.tcp.timewait,/usr/local/zabbix_agent/etc/scripts/networkStatus timewait
　　UserParameter=network.tcp.established,/usr/local/zabbix_agent/etc/scripts/networkStatus established
　　UserParameter=network.tcp.close,/usr/local/zabbix_agent/etc/scripts/networkStatus close
　　

　　到服务端来采集，测试下是不是正常

　　3、在zabbix 服务端创建模板

　　

　　创建 Applications 应用

　　

　　创建监控项目

　　

　　创建图表

　　

　　4、查看监控数据

　　

　　http://www.linuxidc.com/Linux/2012-06/62870.htm
　　onitoring network connection states with Zabbix (+ iptables + iptstate)

Thisis a little howto about displaying some small n’ nice graphs regarding to network connections of your machine. In the way of “Nothing is silly if it involves getting graphs”, the goal of this article is to get a realtime graph showing numbers of current server connections according to protocols,
本文内容英文原文由以下博客作者提供！我做中文说明. 呵呵
http://blog.portwd.com/sysadmin/monitoring-iptables-with-zabbix/
1. iptables, iptstate, zabbix server/agent
2. iptables Zabbix template
3. monitoring scripts
Weneed to get the template from point 2. and import it to Zabbix sever. Then we will rename it’s application from “Network” to e.g. Network_iptables, due to namespace conflict with default Linux template.Now when we have a possibility to display TCP states and type of connections, let’s fill it with data.
/etc/zabbix_agentd.conf:
UserParameter=iptstate.tcp,/etc/zabbix/scripts/net-tcp
UserParameter=iptstate.tcp.syn,/etc/zabbix/scripts/net-syn
UserParameter=iptstate.tcp.timewait,/etc/zabbix/scripts/net-time-wait
UserParameter=iptstate.tcp.established,/etc/zabbix/scripts/net-established
UserParameter=iptstate.tcp.close,/etc/zabbix/scripts/net-close
UserParameter=iptstate.udp,/etc/zabbix/scripts/net-udp
UserParameter=iptstate.icmp,/etc/zabbix/scripts/net-icmp
Boldfont are the names of keys in our newly imported iptables/iptstate zabbix template. Then you need to authorize zabbix user to run iptstate command (potentially without password) and you do it in /etc/sudoers file. Since zabbix agent doesn’t allow to callsudo command directly fromit’s config ( you will end up with error log “you must have a tty to run sudo” ), it is also required to turn off “Defaults requiretty” by commenting it out. The scripts which are called in the example above arelocated in point 3.
#!/bin/bash
est=`sudo iptstate -s | grep ESTABLISHED | wc -l`
echo $est
Outputof this simple script is a number of connections which are in ESTABLISHED TCP state. These checks are periodical, so after restarting zabbix-agentd, you’ll get graphs like from beggining of this article. Good part is that you don’t need to be stuck with defaults, you can define some more like this:
iptstate -s -t | head -2 |tail -1 | sed 's/^.*OTHER: //'
上一张我的图吧，还是热呼呼的，呵呵！


第一步，导入zabbix的关于tcp的模版和脚本文件.见附件！
第二步编辑/etc/zabbix_agentd.conf:
UserParameter=iptstate.tcp,/etc/zabbix/scripts/net-tcp
UserParameter=iptstate.tcp.syn,/etc/zabbix/scripts/net-syn
UserParameter=iptstate.tcp.timewait,/etc/zabbix/scripts/net-time-wait
UserParameter=iptstate.tcp.established,/etc/zabbix/scripts/net-established
UserParameter=iptstate.tcp.close,/etc/zabbix/scripts/net-close
UserParameter=iptstate.udp,/etc/zabbix/scripts/net-udp
UserParameter=iptstate.icmp,/etc/zabbix/scripts/net-icmp
建立脚本文件到/etc/zabbix/scripts这个目录里。
请到这儿下载 http://data.portwd.com/code/zabbix-iptables/
第三步：替换掉/etc/sudoers里的选项
sed -i -e 's/^Defaults.*requiretty/# &/' /etc/sudoers
第三步不做的后果是:
a、zabbix-agentd.log会在你查看关于tcp的图形时，狂报以下信息:
sudo: sorry, you must have a tty to run sudo
第四步重启zabbix-agent
备注1： 在测试中有发现部分机器使用iptstate 没有任何的输出。此时，我们需要加载一个模块。
# modprobe ip_conntrack
关于tcp的脚本，建议先在客户端执行，确认有数字输出,如果本地都没有输出，在zabbix server端也不会有输出。
备注2：在客户端使用zabbix用户执行net-tcp时，出现iptstate  找不到命令。请使用完全路径，我也是在某台vps发现这个问题，我的附件里没有修改。太懒了，原作者的也没有修改。关于iptstate，请使用绝对路径
[root@s10315190 scripts]# cat net-icmp
#!/bin/bash
est=`sudo /usr/sbin/iptstate -s | grep icmp | wc -l`
echo $est
使用zabbix 不超过3天，收获真是不少！官方详尽的文档，不少网站和博客上大量的模版，让我收益良多！
