CCIE_IDS# sh ver
Application Partition:
Cisco Systems Intrusion Detection Sensor, Version 4.1(1)S47
OS Version 2.4.18-5smpbigphys
Platform: IDS-4250
Sensor up-time is 12 min.
Using 326369280 out of 392024064 bytes of available memory (83% usage)
Using 529M out of 6.3G bytes of available disk space (9% usage)
CCIE_IDS# sh interfaces
command-control is up
Internet address is 192.168.0.254, subnet mask is 255.255.255.0, telnet is enabled.
Hardware is eth1, tx
Network Statistics
eth1 Link encap:Ethernet HWaddr 00:0C:29:FE:CC:FB
inet addr:192.168.0.254 Bcast:192.168.0.255 Mask:255.255.255.0
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:3404 errors:0 dropped:0 overruns:0 frame:0
TX packets:2464 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:100
RX bytes:299190 (292.1 Kb) TX bytes:593646 (579.7 Kb)
Interrupt:19 Base address:0x1098 Memory:ec860000-ec880000
Group 0 is up
Sensing ports int0,int2
Logical virtual sensor configuration: virtualSensor
Logical alarm channel configuration: virtualAlarm
VirtualSensor0
General Statistics for this Virtual Sensor
Number of seconds since a reset of the statistics = 838
Measure of the level of resource utilization = 2
Total number of packets processed since reset = 10013
Total number of IP packets processed since reset = 9999
Total number of packets that were not IP processed since reset = 14
Total number of TCP packets processed since reset = 9923
Total number of UDP packets processed since reset = 28
Total number of ICMP packets processed since reset = 48
Total number of packets that were not TCP, UDP, or ICMP processed since reset = 0
Total number of ARP packets processed since reset = 14
Total number of ISL encapsulated packets processed since reset = 0
Total number of 802.1q encapsulated packets processed since reset = 0
Total number of packets with bad IP checksums processed since reset = 0
Total number of packets with bad layer 4 checksums processed since reset = 0
Total number of bytes processed since reset = 1680455
The rate of packets per second since reset = 11
The rate of bytes per second since reset = 2005
The average bytes per packet since reset = 167
Fragment Reassembly Unit Statistics for this Virtual Sensor
Number of fragments currently in FRU = 0
Number of datagrams currently in FRU = 0
Number of fragments received since reset = 0
Number of complete datagrams reassembled since reset = 0
Number of incomplete datagrams abandoned since reset = 0
Number of fragments discarded since reset = 0
Statistics for the TCP Stream Reassembly Unit
Current Statistics for the TCP Stream Reassembly Unit
TCP streams currently in the embryonic state = 0
TCP streams currently in the established state = 0
TCP streams currently in the closing state = 0
TCP streams currently in the system = 1
TCP Packets currently queued for reassembly = 0
Cumulative Statistics for the TCP Stream Reassembly Unit since reset
TCP streams that have been tracked since last reset = 30
TCP streams that had a gap in the sequence jumped = 0
TCP streams that was abandoned due to a gap in the sequence = 0
TCP packets that arrived out of sequence order for their stream = 5
TCP packets that arrived out of state order for their stream = 7509
The rate of TCP connections tracked per second since reset = 0
The Signature Database Statistics.
The Number of each type of node active in the system (can not be reset)
Total nodes active = 16
TCP nodes keyed on both IP addresses and both ports = 1
UDP nodes keyed on both IP addresses and both ports = 1
IP nodes keyed on both IP addresses = 2
The number of each type of node inserted since reset
Total nodes inserted = 105
TCP nodes keyed on both IP addresses and both ports = 18
UDP nodes keyed on both IP addresses and both ports = 2
IP nodes keyed on both IP addresses = 9
The rate of nodes per second for each time since reset
Nodes per second = 0
TCP nodes keyed on both IP addresses and both ports per second = 0
UDP nodes keyed on both IP addresses and both ports per second = 0
IP nodes keyed on both IP addresses per second = 0
The number of root nodes forced to expire because of memory constraints
TCP nodes keyed on both IP addresses and both ports = 0
Alarm Statistics for this Virtual Sensor
Number of alarms triggered by events = 20
Number of alarms excluded by filters = 0
Number of alarms removed by summarizer = 0
Number of alarms sent to the Event Store = 20
Sensing int0 is up
Hardware is eth0, TX
Reset port
MAC statistics from the Gig Ethernet Interface int0
Missed Packet Percentage = 0
Link Status = Up
Total Packets Received = 5003
Total Bytes Received = 840047
Total Receive Errors = 0
Total multicast packets received = 0
Total Receive Length Errors = 0
Total Receive Overrun Errors = 0
Total Receive CRC Errors = 0
Total Receive Frame Errors = 0
Total Receive FIFO Errors = 0
Total Receive Missed Errors = 0
Total Packets Transmitted = 0
Total Bytes Transmitted = 0
Total Transmit Errors = 0
Transmit drops due to lack of resources = 0
Total Transmit Packet Collisions = 0
Total Transmit Aborted Errors = 0
Total Transmit Carrier Errors = 0
Total Transmit FIFO Errors = 0
Total Transmit Heartbeat Errors = 0
Total Transmit Window Errors = 0
Sensing int2 is up
Hardware is eth2, TX
Reset port
MAC statistics from the Gig Ethernet Interface int2
Missed Packet Percentage = 0
Link Status = Up
Total Packets Received = 4940
Total Bytes Received = 835784
Total Receive Errors = 0
Total multicast packets received = 0
Total Receive Length Errors = 0
Total Receive Overrun Errors = 0
Total Receive CRC Errors = 0
Total Receive Frame Errors = 0
Total Receive FIFO Errors = 0
Total Receive Missed Errors = 0
Total Packets Transmitted = 0
Total Bytes Transmitted = 0
Total Transmit Errors = 0
Transmit drops due to lack of resources = 0
Total Transmit Packet Collisions = 0
Total Transmit Aborted Errors = 0
Total Transmit Carrier Errors = 0
Total Transmit FIFO Errors = 0
Total Transmit Heartbeat Errors = 0
Total Transmit Window Errors = 0
