安全套接字层 (SSL) 技术通过加密信息和提供鉴权，保护您的网站安全。一份 SSL 证书包括一个公共密钥和一个私用密钥。公共密钥用于加密信息，私用密钥用于解译加密的信息。浏览器指向一个安全域时，SSL 同步确认服务器和客户端，并创建一种加密方式和一个唯一的会话密钥。它们可以启动一个保证消息的隐私性和完整性的安全会话。
首先要有一个主证书，然后用主证书来签发服务器证书和客户证书，服务器证书和客户证书是平级关系，SSL所使用的证书可以自己生成，也可以通过一个商业性CA（如Verisign 或 Thawte）签署证书。签发证书的问题：如果使用的是商业证书，具体的签署方法请查看相关销售商的说明；如果是知己签发的证书，可以使用openssl 自带的CA.sh脚本工具。如果不为单独的客户端签发证书，客户端证书可以不用生成，客户端与服务器端使用相同的证书。 二，安装所要的软件
openssl ：wget http://www.openssl.org/source/openssl-1.0.0a.tar.gz
apache： wget http://www.apache.org/dist/httpd/httpd-2.2.16.tar.gz 三，安装
在正式安装前，请不要直接看下面的安装，请看最后一部分，那是我安装时候所遇到的问题，这样可以使你少走不少弯路，我安装的时候，就走了不少弯路。 1，安装openssl
tar zxvf openssl-1.0.0a.tar.gz
cd openssl-1.0.0a
./config –prefix=/usr/local/openssl
make && make install 2,安装apache
如果你已经安装了apache，你又不想重新编译的话，请参考mod_ssl模块的安装，也就是添加ssl模块而已。
tar zxvf httpd-2.2.16.tar.gz
cd httpd-2.2.16
./configure –prefix=/usr/local/apache –enable-ssl –enable-rewrite –enable-so –with-ssl=/usr/local/openssl
make && make install
如果你是yum install ,apt-get,pacman这样的软件管理工具进行安装的话，上面的二步可以省掉。 3，创建主证书
在/usr/local/apache/conf/下面建个目录ssl
3.1，mkdir ssl
3.2，cp /openssl的安装目录/ssl/misc/CA.sh /usr/local/apache/conf/ssl/
3.3 用CA.sh来创建证书
1 [iyunv@BlackGhost ssl]# ./CA.sh -newca //建立主证书
2 CA certificate filename (or enter to create)
3
4 Making CA certificate ...
5 Generating a 1024 bit RSA private key
6 ............++++++
7 ......++++++
8 writing new private key to './demoCA/private/./cakey.pem'
9 Enter PEM pass phrase:
10 Verifying - Enter PEM pass phrase:
11 Verify failure
12 Enter PEM pass phrase:
13 Verifying - Enter PEM pass phrase:
14 -----
15 You are about to be asked to enter information that will be incorporated
16 into your certificate request.
17 What you are about to enter is what is called a Distinguished Name or a DN.
18 There are quite a few fields but you can leave some blank
19 For some fields there will be a default value,
20 If you enter '.', the field will be left blank.
21 -----
22 Country Name (2 letter code) [AU]:cn
23 State or Province Name (full name) [Some-State]:cn
24 Locality Name (eg, city) []:cn
25 Organization Name (eg, company) [Internet Widgits Pty Ltd]:cn
26 Organizational Unit Name (eg, section) []:cn
27 Common Name (eg, YOUR name) []:localhost
28 Email Address []:xtaying@gmail.com
29
30 Please enter the following 'extra' attributes
31 to be sent with your certificate request
32 A challenge password []:******************
33 An optional company name []:
34 Using configuration from /etc/ssl/openssl.cnf
35 Enter pass phrase for ./demoCA/private/./cakey.pem: //填的是上面的PEM密码
36 Check that the request matches the signature
37 Signature ok
38 Certificate Details:
39 Serial Number:
40 89:11:9f:a6:ca:03:63:ab
41 Validity
42 Not Before: Aug 7 12:35:28 2010 GMT
43 Not After : Aug 6 12:35:28 2013 GMT
44 Subject:
45 countryName = cn
46 stateOrProvinceName = cn
47 organizationName = cn
48 organizationalUnitName = cn
49 commonName = localhost
50 emailAddress = xtaying@gmail.com
51 X509v3 extensions:
52 X509v3 Subject Key Identifier:
53 26:09:F3:D5:26:13:00:1F:3E:CC:86:1D:E4:EE:37:06:65:15:4E:76
54 X509v3 Authority Key Identifier:
55 keyid:26:09:F3:D5:26:13:00:1F:3E:CC:86:1D:E4:EE:37:06:65:15:4E:76
56 DirName:/C=cn/ST=cn/O=cn/OU=cn/CN=localhost/emailAddress=xtaying@gmail.com
57 serial:89:11:9F:A6:CA:03:63:AB
58
59 X509v3 Basic Constraints:
60 CA:TRUE
61 Certificate is to be certified until Aug 6 12:35:28 2013 GMT (1095 days)
62
63 Write out database with 1 new entries
64 Data Base Updated
安装成功的话，会在ssl目录下面产生一个文件夹demoCA 4 生成服务器私钥和服务器证书
1 [iyunv@BlackGhost ssl]# openssl genrsa -des3 -out server.key 1024 //产生服务器私钥
2 Generating RSA private key, 1024 bit long modulus
3 .....................++++++
4 .........++++++
5 e is 65537 (0x10001)
6 Enter pass phrase for server.key:
7 Verifying - Enter pass phrase for server.key:
8 [iyunv@BlackGhost ssl]# openssl req -new -key server.key -out server.csr //生成服务器证书
9 Enter pass phrase for server.key:
10 You are about to be asked to enter information that will be incorporated
11 into your certificate request.
12 What you are about to enter is what is called a Distinguished Name or a DN.
13 There are quite a few fields but you can leave some blank
14 For some fields there will be a default value,
15 If you enter '.', the field will be left blank.
16 -----
17 Country Name (2 letter code) [AU]:cn
18 State or Province Name (full name) [Some-State]:cn
19 Locality Name (eg, city) []:cn
20 Organization Name (eg, company) [Internet Widgits Pty Ltd]:cn
21 Organizational Unit Name (eg, section) []:cn
22 Common Name (eg, YOUR name) []:localhost //要填全域名
23 Email Address []:xtaying@gmail.com
24
25 Please enter the following 'extra' attributes
26 to be sent with your certificate request
27 A challenge password []:*****************
28 An optional company name []:
29 4.1 对产生的服务器证书进行签证
30
31 cp server.csr newseq.pem
32
33 查看复制打印?
34 [iyunv@BlackGhost ssl]# ./CA.sh -sign //为服务器证书签名
35 Using configuration from /etc/ssl/openssl.cnf
36 Enter pass phrase for ./demoCA/private/cakey.pem:
37 Check that the request matches the signature
38 Signature ok
39 Certificate Details:
40 Serial Number:
41 89:11:9f:a6:ca:03:63:ac
42 Validity
43 Not Before: Aug 7 12:39:41 2010 GMT
44 Not After : Aug 7 12:39:41 2011 GMT
45 Subject:
46 countryName = cn
47 stateOrProvinceName = cn
48 localityName = cn
49 organizationName = cn
50 organizationalUnitName = cn
51 commonName = localhost
52 emailAddress = xtaying@gmail.com
53 X509v3 extensions:
54 X509v3 Basic Constraints:
55 CA:FALSE
56 Netscape Comment:
57 OpenSSL Generated Certificate
58 X509v3 Subject Key Identifier:
59 FE:20:56:04:8E:B6:BE:3E:3A:E1:DA:A6:4A:3A:E1:16:93:1D:3F:81
60 X509v3 Authority Key Identifier:
61 keyid:26:09:F3:D5:26:13:00:1F:3E:CC:86:1D:E4:EE:37:06:65:15:4E:76
62
63 Certificate is to be certified until Aug 7 12:39:41 2011 GMT (365 days)
64 Sign the certificate? [y/n]:y
65
66 1 out of 1 certificate requests certified, commit? [y/n]y
67 Write out database with 1 new entries
68 Data Base Updated
69 Certificate:
70 Data:
71 Version: 3 (0x2)
72 Serial Number:
73 89:11:9f:a6:ca:03:63:ac
74 Signature Algorithm: sha1WithRSAEncryption
75 Issuer: C=cn, ST=cn, O=cn, OU=cn, CN=localhost/emailAddress=xtaying@gmail.com
76 Validity
77 Not Before: Aug 7 12:39:41 2010 GMT
78 Not After : Aug 7 12:39:41 2011 GMT
79 Subject: C=cn, ST=cn, L=cn, O=cn, OU=cn, CN=localhost/emailAddress=xtaying@gmail.com
80 Subject Public Key Info:
81 Public Key Algorithm: rsaEncryption
82 Public-Key: (1024 bit)
83 Modulus:
84 00:ce:d5:a8:df:d1:e7:ee:92:d1:d1:78:20:a9:6d:
85 0a:1b:f6:09:dd:13:29:ef:72:1d:17:54:dd:1c:8d:
86 28:27:69:fe:70:3b:fa:2b:a3:45:40:80:ea:0e:5b:
87 a7:bd:40:d0:cd:bc:2c:74:03:8b:f7:6c:5e:1f:09:
88 5d:c6:8a:05:ea:b8:72:fc:79:8b:62:62:38:0b:42:
89 28:7e:0d:fc:e7:bb:b0:87:66:6a:b2:35:92:91:b9:
90 78:9c:b6:76:01:0b:2a:74:df:5f:a1:8b:31:61:90:
91 93:f9:20:db:46:59:12:2e:9b:59:c0:32:4e:92:14:
92 a1:7e:52:7b:cc:02:5e:e2:45
93 Exponent: 65537 (0x10001)
94 X509v3 extensions:
95 X509v3 Basic Constraints:
96 CA:FALSE
97 Netscape Comment:
98 OpenSSL Generated Certificate
99 X509v3 Subject Key Identifier:
100 FE:20:56:04:8E:B6:BE:3E:3A:E1:DA:A6:4A:3A:E1:16:93:1D:3F:81
101 X509v3 Authority Key Identifier:
102 keyid:26:09:F3:D5:26:13:00:1F:3E:CC:86:1D:E4:EE:37:06:65:15:4E:76
103
104 Signature Algorithm: sha1WithRSAEncryption
105 09:a0:16:43:a2:93:11:a7:ab:f5:17:b7:36:35:84:9f:3b:37:
106 32:33:3f:93:63:b0:4c:bb:d1:b4:9b:4f:37:78:62:f4:ac:ff:
107 28:b0:63:71:2e:9a:7c:f4:40:2e:b1:5f:ae:49:e7:e2:6f:de:
108 cf:30:cc:9a:08:26:26:24:c5:00:03:32:20:48:41:b1:29:8f:
109 5d:3d:2a:78:54:0e:a8:76:07:6c:7f:23:42:75:c2:fb:83:1d:
110 70:44:5e:8c:90:cf:b4:23:b7:23:5b:06:05:32:58:e3:af:1c:
111 be:1d:50:7b:fd:37:66:ba:9c:ec:bb:af:ee:b6:04:f7:c5:2e:
112 59:22
113 -----BEGIN CERTIFICATE-----
114 MIIC2jCCAkOgAwIBAgIJAIkRn6bKA2OsMA0GCSqGSIb3DQEBBQUAMGoxCzAJBgNV
115 BAYTAmNuMQswCQYDVQQIEwJjbjELMAkGA1UEChMCY24xCzAJBgNVBAsTAmNuMRIw
116 EAYDVQQDEwlsb2NhbGhvc3QxIDAeBgkqhkiG9w0BCQEWEXh0YXlpbmdAZ21haWwu
117 Y29tMB4XDTEwMDgwNzEyMzk0MVoXDTExMDgwNzEyMzk0MVowdzELMAkGA1UEBhMC
118 Y24xCzAJBgNVBAgMAmNuMQswCQYDVQQHDAJjbjELMAkGA1UECgwCY24xCzAJBgNV
119 BAsMAmNuMRIwEAYDVQQDDAlsb2NhbGhvc3QxIDAeBgkqhkiG9w0BCQEWEXh0YXlp
120 bmdAZ21haWwuY29tMIGfMA0GCSqGSIb3DQEBAQUAA4GNADCBiQKBgQDO1ajf0efu
121 ktHReCCpbQob9gndEynvch0XVN0cjSgnaf5wO/oro0VAgOoOW6e9QNDNvCx0A4v3
122 bF4fCV3GigXquHL8eYtiYjgLQih+Dfznu7CHZmqyNZKRuXictnYBCyp031+hizFh
123 kJP5INtGWRIum1nAMk6SFKF+UnvMAl7iRQIDAQABo3sweTAJBgNVHRMEAjAAMCwG
124 CWCGSAGG+EIBDQQfFh1PcGVuU1NMIEdlbmVyYXRlZCBDZXJ0aWZpY2F0ZTAdBgNV
125 HQ4EFgQU/iBWBI62vj464dqmSjrhFpMdP4EwHwYDVR0jBBgwFoAUJgnz1SYTAB8+
126 zIYd5O43BmUVTnYwDQYJKoZIhvcNAQEFBQADgYEACaAWQ6KTEaer9Re3NjWEnzs3
127 MjM/k2OwTLvRtJtPN3hi9Kz/KLBjcS6afPRALrFfrknn4m/ezzDMmggmJiTFAAMy
128 IEhBsSmPXT0qeFQOqHYHbH8jQnXC+4MdcERejJDPtCO3I1sGBTJY468cvh1Qe/03
129 Zrqc7Luv7rYE98UuWSI=
130 -----END CERTIFICATE-----
131 Signed certificate is in newcert.pem
