zabbix监控mysql

wiuyiyi · 发表于 2015-9-8 09:14:43

1、zabbix添加mysql的监控模板（template-app-mysql）之后，还需要在客户端添加key去取值。
2、编写脚本，获取mysql的各种状态值。可以固定一个目录，专门存放监控脚本。比如/usr/local/zabbix/scripts/chk_mysql.sh
#!/bin/bash

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88

# -------------------------------------------------------------------------------
# FileName: chk_mysql.sh
# Revision: 1.0
# Date:       2015/09/07
# Author:    Winngins Yu
# Email:    drinkboy@126.com
# Website:    www.drinkboy.com
# Description:
# Notes:    ~
# -------------------------------------------------------------------------------
# Copyright: 2015 (c) Winngins Yu
# License:    GPL

# 用户名
MYSQL_USER='root'

# 密码
MYSQL_PWD='liujinWANG1985'

# 主机地址/IP
MYSQL_HOST='127.0.0.1'

# 端口
MYSQL_PORT='3306'

# 数据连接
MYSQL_CONN="/alidata/mysql/bin/mysqladmin -u ${MYSQL_USER} -p${MYSQL_PWD} -h${MYSQL_HOST} -P${MYSQL_PORT}"

# 参数是否正确
if [ $# -ne "1" ];then
echo "arg error!"
fi

# 获取数据
case $1 in
Uptime)
      result=`${MYSQL_CONN} status|cut -f2 -d":"|cut -f1 -d"T"`
      echo $result
      ;;
Com_update)
      result=`${MYSQL_CONN} extended-status |grep -w "Com_update"|cut -d"|" -f3`
      echo $result
      ;;
Slow_queries)
      result=`${MYSQL_CONN} status |cut -f5 -d":"|cut -f1 -d"O"`
      echo $result
      ;;
Com_select)
      result=`${MYSQL_CONN} extended-status |grep -w "Com_select"|cut -d"|" -f3`
      echo $result
            ;;
Com_rollback)
      result=`${MYSQL_CONN} extended-status |grep -w "Com_rollback"|cut -d"|" -f3`
            echo $result
            ;;
Questions)
      result=`${MYSQL_CONN} status|cut -f4 -d":"|cut -f1 -d"S"`
            echo $result
            ;;
Com_insert)
      result=`${MYSQL_CONN} extended-status |grep -w "Com_insert"|cut -d"|" -f3`
            echo $result
            ;;
Com_delete)
      result=`${MYSQL_CONN} extended-status |grep -w "Com_delete"|cut -d"|" -f3`
            echo $result
            ;;
Com_commit)
      result=`${MYSQL_CONN} extended-status |grep -w "Com_commit"|cut -d"|" -f3`
            echo $result
            ;;
Bytes_sent)
      result=`${MYSQL_CONN} extended-status |grep -w "Bytes_sent" |cut -d"|" -f3`
            echo $result
            ;;
Bytes_received)
      result=`${MYSQL_CONN} extended-status |grep -w "Bytes_received" |cut -d"|" -f3`
            echo $result
            ;;
Com_begin)
      result=`${MYSQL_CONN} extended-status |grep -w "Com_begin"|cut -d"|" -f3`
            echo $result
            ;;

      *)
      echo "Usage:$0(Uptime|Com_update|Slow_queries|Com_select|Com_rollback|Questions|Com_insert|Com_delete|Com_commit|Bytes_sent|Bytes_received|Com_begin)"
      ;;
esac

3、修改zabbix的配置文件/usr/local/zabbix-agentd/etc/zabbix_agentd.conf，添加

1
2
3
4
5
6
7

#获取mysql版本
UserParameter=mysql.version,mysql -V
##获取mysql性能指标,这个是上面定义好的脚本
UserParameter=mysql.status

,bash /alidata/zabbix-agentd/scripts/chk_mysql.sh $1
##获取mysql运行状态
UserParameter=mysql.ping,/alidata/mysql/bin/mysqladmin -uroot -pliujinWANG1985 -P3306 -h127.0.0.1 ping | grep -c alive
UserParameter=mysql.process,/alidata/mysql/bin/mysql -uroot -pliujinWANG1985 -P3306 -h127.0.0.1 -e "show processlist" 2>/dev/null|wc -l

4、重启zabbix的客户端
