Transparent Huge Pages的一些官方介绍资料:
Transparent Huge Pages (THP) are enabled by default in RHEL 6 for all applications. The kernel attempts to allocate hugepages whenever possible and any Linux process will receive 2MB pages if the mmap region is 2MB naturally aligned. The main kernel address space itself is mapped with hugepages, reducing TLB pressure from kernel code. For general information on Hugepages, see: What are Huge Pages and what are the advantages of using them?
The kernel will always attempt to satisfy a memory allocation using hugepages. If no hugepages are available (due to non availability of physically continuous memory for example) the kernel will fall back to the regular 4KB pages. THP are also swappable (unlike hugetlbfs). This is achieved by breaking the huge page to smaller 4KB pages, which are then swapped out normally.
But to use hugepages effectively, the kernel must find physically continuous areas of memory big enough to satisfy the request, and also properly aligned. For this, a khugepaged kernel thread has been added. This thread will occasionally attempt to substitute smaller pages being used currently with a hugepage allocation, thus maximizing THP usage.
In userland, no modifications to the applications are necessary (hence transparent). But there are ways to optimize its use. For applications that want to use hugepages, use of posix_memalign() can also help ensure that large allocations are aligned to huge page (2MB) boundaries.
Also, THP is only enabled for anonymous memory regions. There are plans to add support for tmpfs and page cache. THP tunables are found in the /sys tree under /sys/kernel/mm/redhat_transparent_hugepage.
2:命令
Node 0, zone Normal 4033 5345 34166 41732 38549 26725 15639 9526 6372 1410 15443
原文解释
/proc/buddyinfo
This file is used primarily for diagnosing memory fragmentation issues. Using the buddy algorithm, each column represents the number of pages of a certain order (a certain>PAGE_SIZE) chunks of memory. Similarly, there are 6 of 2^(1PAGE_SIZE) chunks, and 2 of 2^(2*PAGE_SIZE) chunks of memory available.
The DMA row references the first 16 MB on a system, the HighMem row references all memory greater than 4 GB on a system, and the Normal row references all memory in between.
The following is an example of the output typical of /proc/buddyinfo:
Node 0, zone Normal 3450 214 31052 41870 38553 26732 15642 9527 6373 1406 15443
Each column of numbers represents the number of pages of that order which are available. In the example below, there are 7 chunks of 2 ^ 0 * PAGE_SIZE available in ZONE_DMA, and 12 chunks of 2 ^ 3 * PAGE_SIZE available in ZONE_NORMAL, etc...
This information can give you a good> 下面这段话很重要
When a Linux system has been running for a while memory fragmentation can increase which depends heavily on the nature of the applications that are running on it. The more processes allocate and free memory, the quicker memory becomes fragmented. And the kernel may not always be able to defragment enough memory for a requested> 想看memory fragmentation 可以执行: echo m > /proc/sysrq-trigger
To see memory fragmentation you can use the magic SysRq key. Simply execute the following command:
# echo m > /proc/sysrq-trigger
This command will dump current memory information to /var/log/messages.
如果执行:echo m > /proc/sysrq-trigger 没有输出,那是因为你的sysrq没有enable,需要执行如下:
# echo 1 > /proc/sys/kernel/sysrq
Starting with the 2.6 kernel, i.e. RHEL4 and SLES9, you don’t need SysRq to dump memory information. You can simply check /proc/buddyinfo for memory fragmentation.
其实,从kernel2.6 开始,不需要执行:echo m > /proc/sysrq-trigger 才能dump memory information,也可以直接看/proc/buddyinfo文件
