双核心冗余结构下的网络架构中,HSRP,VRRP,STP都是最常用的几种技术。Cisco命名为HSRP(热备份路由协议),华为与H3C等国内的厂商称为虚拟路由冗余协议。名称不同但配置过程与作用却是类似的。 典型的网络结构如下图所示
此处我以client 1作为内网,ip地址段192.168.1.0/24 ,属于vlan3. lsw1与ar1连接处使用10.10.10.0/30, Lsw2与ar1连接处使用20.20.20.0/30,client2作为目标网段,使用30.30.30.0/24.路由器与交换机上跑OSPF协议,LSW1作为活跃路由器。 配置前的准备工作例如IP地址,主要是看VRRP的配置。 LSW3配置 [LSW3]vlan 3 [LSW3-vlan3]quit [LSW3]int e0/0/3 [LSW3-Ethernet0/0/3]port link-type access [LSW3-Ethernet0/0/3]port default vlan 3 [LSW3-Ethernet0/0/3]quit [LSW3]int e0/0/1 [LSW3-Ethernet0/0/1]port link-type trunk [LSW3-Ethernet0/0/1]port trunk allow-pass vlan all [LSW3-Ethernet0/0/1]quit [LSW3]int e0/0/2 [LSW3-Ethernet0/0/2]port link-type trunk [LSW3-Ethernet0/0/2]port trunk allow-pass vlan all [LSW3-Ethernet0/0/2]quit LSW1上的配置 [LSW1]vlan 20 [LSW1-vlan20]quit [LSW1]int vlan 20 [LSW1-Vlanif20]ip add 10.10.10.1 30 [LSW1-Vlanif20]quit [LSW1]int e0/0/1 [LSW1-Ethernet0/0/1]port link-type trunk [LSW1-Ethernet0/0/1]port trunk allow-pass vlan all [LSW1-Ethernet0/0/1]quit [LSW1]int e0/0/2 [LSW1-Ethernet0/0/2]port link-type access [LSW1-Ethernet0/0/2]port default vlan 20 [LSW1-Ethernet0/0/2]quit
[LSW1]ospf 1 [LSW1-ospf-1]are 0 [LSW1-ospf-1-area-0.0.0.0]network 192.168.1.0 0.0.0.255 [LSW1-ospf-1-area-0.0.0.0]network 10.10.10.0 0.0.0.3 [LSW1-ospf-1-area-0.0.0.0]quit [LSW1]vlan 3 [LSW1-vlan3]quit [LSW1]int vlan 3 [LSW1-Vlanif3]ip address 192.168.1.100 24 [LSW1-Vlanif3]quit [LSW1-Vlanif3]vrrp vrid 1 virtual-ip 192.168.1.1 //虚拟ip [LSW1-Vlanif3]vrrp vrid 1 priority 200 //优先级 [LSW1-Vlanif3]vrrp vrid 1 preempt-mode timer delay 5 //在5s后进行抢占 [LSW1-Vlanif3]vrrp vrid 1 track interface Ethernet 0/0/2 reduced 100 //当发现端口down掉后优先级降低100, LSW2 [LSW2]vlan 20 [LSW2-vlan20]quit [LSW2]int vlan 20 [LSW2-Vlanif20]ip add 20.20.20.1 30 [LSW2-Vlanif20]quit [LSW2]int e0/0/1 [LSW2-Ethernet0/0/1]port link-type trunk [LSW2-Ethernet0/0/1]port trunk allow-pass vlan all [LSW2]int e0/0/2 [LSW2-Ethernet0/0/2]port link-type access [LSW2-Ethernet0/0/2]port default vlan 20 [LSW2-Ethernet0/0/2]quit [LSW2]ospf 1 [LSW2-ospf-1]area 0 [LSW2-ospf-1-area-0.0.0.0]network 192.168.1.0 0.0.0.255 [LSW2-ospf-1-area-0.0.0.0]network 20.20.20.0 0.0.0.3 [LSW2-ospf-1-area-0.0.0.0]quit [LSW2-ospf-1] [LSW2]vlan 3 [LSW2-vlan3]quit [LSW2]int vlan 3 [LSW2-Vlanif3]ip add 192.168.1.200 24 [LSW2-Vlanif3]vrrp vrid 1 virtual-ip 192.168.1.1 [LSW2-Vlanif3]vrrp vrid 1 priority 120 [LSW2-Vlanif3]vrrp vrid 1 preempt-mode timer delay 5 AR1 <AR1>sys Enter system view, return user view with Ctrl+Z. [AR1]int g0/0/0 [AR1-GigabitEthernet0/0/0]ip add 10.10.10.2 30 [AR1-GigabitEthernet0/0/0]quit [AR1]int g0/0/1 [AR1-GigabitEthernet0/0/1]quit [AR1]int g0/0/2 [AR1-GigabitEthernet0/0/2]ip add 30.30.30.1 24 [AR1-GigabitEthernet0/0/2]quit [AR1-ospf-1]area 0 [AR1-ospf-1-area-0.0.0.0]network 10.10.10.0 0.0.0.3 [AR1-ospf-1-area-0.0.0.0]network 20.20.20.0 0.0.0.3 [AR1-ospf-1-area-0.0.0.0]network 30.30.30.0 0.0.0.255 配置完毕后在CLIENT1上PING CLIENT2
查看VRRP组的状态 [LSW1]display vrrp 1 Vlanif3 | Virtual Router 1 State : Master Virtual IP : 192.168.1.1 Master IP : 192.168.1.100 PriorityRun : 200 PriorityConfig : 200 MasterPriority : 200 Preempt : YES Delay Time : 5 s TimerRun : 1 s TimerConfig : 1 s Auth type : NONE Virtual MAC : 0000-5e00-0101 Check TTL : YES Config type : normal-vrrp Track IF : Ethernet0/0/2 Priority reduced : 100 IF state : UP Create time : 2013-04-27 18:13:50 UTC-08:00 Last change time : 2013-04-27 18:30:33 UTC-08:00 [LSW2]disp vrrp 1 Vlanif3 | Virtual Router 1 State : Backup Virtual IP : 192.168.1.1 Master IP : 192.168.1.100 PriorityRun : 120 PriorityConfig : 120 MasterPriority : 200 Preempt : YES Delay Time : 5 s TimerRun : 1 s TimerConfig : 1 s Auth type : NONE Virtual MAC : 0000-5e00-0101 Check TTL : YES Config type : normal-vrrp Create time : 2013-04-27 18:17:01 UTC-08:00 Last change time : 2013-04-27 18:55:32 UTC-08:00 将LSW1连接路由器的接口关闭再观察vrrp状态 [LSW1]disp vrrp 1 Vlanif3 | Virtual Router 1 State : Backup Virtual IP : 192.168.1.1 Master IP : 192.168.1.200 PriorityRun : 100 PriorityConfig : 200 MasterPriority : 120 Preempt : YES Delay Time : 5 s TimerRun : 1 s TimerConfig : 1 s Auth type : NONE Virtual MAC : 0000-5e00-0101 Check TTL : YES Config type : normal-vrrp Track IF : Ethernet0/0/2 Priority reduced : 100 IF state : DOWN Create time : 2013-04-27 18:13:50 UTC-08:00 Last change time : 2013-04-27 19:03:03 UTC-08:00 [LSW2]disp vrrp 1 Vlanif3 | Virtual Router 1 State : Master Virtual IP : 192.168.1.1 Master IP : 192.168.1.200 PriorityRun : 120 PriorityConfig : 120 MasterPriority : 120 Preempt : YES Delay Time : 5 s TimerRun : 1 s TimerConfig : 1 s Auth type : NONE Virtual MAC : 0000-5e00-0101 Check TTL : YES Config type : normal-vrrp Create time : 2013-04-27 18:17:01 UTC-08:00 Last change time : 2013-04-27 19:03:02 UTC-08:00 切换期间客户端之间的通信丢了一个数据包
|
